necessity to fill in water. Make sure to turn the water off turn the steam control (12) to

 position, i.e. turn it

clockwise, so the sign

 will cover the marker on the casing of the espresso machine. Open the water tank

cover (1) and pour in the water. After replenishing water, the sound signal will stop. To continue with the hot
water mode turn the steam control (12) to position

, i.e. turn it counterclockwise, so the sign

 will

cover the casing of the espresso machine.

CAUTION! Moving the steam/hot water nozzle (10) is possible only by means of a special attachment (Fig. 9). The
steam/hot water nozzle (10) is extremely hot.

Fig. 8

Fig. 9

16. Automatic shutdown function

The machine will turn itself off automatically, if it is not used for over an hour. To turn it on again press the power on/off
button

(A)

 – you should hear a sound signal afterwards.

17. Emptying the drip tray

When the drip tray

(8)

 is filled with water, its red emptiness gauge

(9)

 will rise above the

drip tray grid

(7)

. Pull out the drip tray

(8)

 with the grid

(7)

 out of the espresso machine and

pour the water out

(Fig. 10)

. Place the accessories back in the machine.

Fig. 10

18. Removing limescale

Limescale is a mineral residue, which forms a natural deposit on all devices responsible for heating up water. This is why
limescale needs to be removed from the espresso periodically. When a certain amount of water is used by the machine

(this amount depends on its hardness level set in the machine) the display panel should indicate a flashing

. It is

a signal for the user to remove limescale by means of

citric acid

.

Important:

 When removing calcareous residues it is necessary to use

a limescale removing solution

, prepared in the

following manner: Dissolve two spoons (ca. 30 grams) of citric acid in

ONE

 liter of water.

18.1. Unplug the espresso machine from the power supply.
18.2. Make sure that the espresso machine has cooled off.
18.3. Remove the water tank

(1)

 and the drip tray

(8)

 together with its grid

(7)

 from the espresso machine

(Fig. 11)

.

18.4. Place the espresso machine upside-down and undo the grid from the filter head

(4)

 by means of an

appropriate screwdriver

(Fig. 12)

.

18.5. Clean the filter grid and filter head

(4)

, remove limescale and coffee remains.

18.6. Place the espresso machine in the upright, working position.
18.7. Fill the water tank

(1)

 with the prepared solution based on citric acid.

18.8. Close the cover of the water tank

(1)

, and then install the tank

(1)

 and the drip tray

(8)

 with its grid

(7)

 back into

the espresso machine

(Fig. 13)

.

18.9. Plug the espresso machine by putting the cord into the socket. The machine will turn on. The display panel and

the power on/off button

(A)

 will flash. The display panel will indicate power is on

.

18.10. Push the power on/off button

(A)

. You will hear a sound signal.

18.11. The

 indicator on the display panel will begin to whirl, signalizing that the espresso machine is heating up.

18.12. When the

 indicator stops whirling, you will hear a sound signal informing you that the machine is ready for

use (has reached the right temperature).

18.13. Press and hold both the coffee amount select button

(C)

and the steam/hot water select button

(E)

for

2 seconds. The remove limescale indicator will stop flashing

, while the indicator

 will start whirling

informing that the process of removing limescale has begun.

18.14. Hot water with removed limescale will pour out of the brew head

(4)

.

  114
