0478 111 9926 A - EN
38
Wear limits
The blade thickness (A) must be at least
2 mm
at any point. The most important
points are marked in the illustration.
The cutting edges must not be ground
back by more than
5 mm
– distance (B)
(permissible grinding) during sharpening.
1
2.3 Sharpening the mowing blade
If you do not have the necessary expertise
or auxiliary equipment, we recommend
that you have the blade sharpened by a
specialist dealer. Operation of the machine
is impaired in the case of an incorrectly
sharpened blade (incorrect sharpening
angle, imbalance etc.).
Sharpening instructions
●
Remove the mowing blade. (
●
Cool the mowing blade during
sharpening, e.g. with water.
The blade must not be allowed to
display blue colouring, as this would
reduce its cutting quality.
●
Sharpen blades evenly to prevent
vibration due to imbalance.
●
Observe a sharpening angle of
30°
.
●
Observe the wear limits (
1
2.4 Removing and installing the
mowing blade
Removing
●
Hold the mowing blade (1) and loosen
the blade fastening screw (2).
●
Remove the blade fastening screw (2),
retaining washer (3) and mowing
blade (1).
Installing
●
Clean the blade contact surface and
blade bushing (4).
●
Secure the blade fastening screw (2)
with
Loctite 243
.
●
Place the mowing blade (1) on the
blade bushing (4) as shown.
●
Position the retaining washer (3) as
shown and tighten with the blade
fastening screw (2) to
60
-
65 Nm
.
1
2.5 Engine
Maintenance interval:
See engine instruction manual.
General information:
Observe the operating and maintenance
instructions contained in the attached
engine instruction manual.
To achieve a long service life, it is always
particularly important to maintain a
sufficient level of oil and to change the oil
and air filter regularly.
The recommended oil change intervals as
well as information on engine oil and oil
capacities can also be found in the engine
instruction manual.
The cooling ribs must always be kept clean
to ensure that the engine is adequately
cooled.
1
2.6 Wheels and gearbox
The wheel bearings are maintenance-free.
The gearbox is maintenance-free.
1
2.7 Storage (winter break)
Note the following points when storing the
machine for long periods (winter break):
●
Clean all external parts of the machine
with care.
●
Thoroughly lubricate/grease all moving
parts.
●
Empty the fuel tank and carburettor
(e.g. by running empty).
●
Unscrew the spark plug (see engine
instruction manual) and pour approx.
3 cm³ of engine oil into the engine via
the spark plug hole. Turn the engine
several times with the spark plug
removed (pull the recoil starter rope).
Risk of injury!
Always wear gloves.
The mowing blade must
be replaced if notches or
cracks are detected or if a wear
limit is reached (
1
4
Risk of injury!
The prescribed tightening torque
for the blade fastening screw must
be observed.
The retaining washer (3) must be
replaced each time the blade is
installed.
The blade fastening screw (2) must
be renewed each time the blade is
replaced.
Fire hazard!
Keep the spark plug socket away
from the spark plug hole due to the
danger of ignition.
