An escape path should be planned and cleared as
necessary before cuts are started. The escape path should
extend back and diagonally to the rear of the expected line
of fall.
Before felling is started, consider the natural lean of the
tree, the location of larger branches and the wind direction
to judge which way the tree will fall.
Remove dirt, stones, loose bark, nails, staples and wire
from the tree.
Do not attempt to fell trees which are rotten or have been
damaged by wind,

¿

 re, lightning, etc. This is extremely

dangerous and should only be completed by professional
tree surgeons.

1. Notching undercut

See page 251 - 252.

Make the notch 1/3 the diameter of the tree,
perpendicular to the direction of falls. Make the lower
horizontal notching cut first. This will help to avoid
pinching either the saw chain or the guide bar when the
second notch is being made.

2.  Felling back cut

See page 251 - 252.

Make the felling back cut at least 50 mm/2 in higher
than the horizontal notching cut. Keep the felling back
cut parallel to the horizontal notching cut. Make the
felling back cut so enough wood is left to act as a hinge.
The hinge wood keeps the tree from twisting and falling
in the wrong direction. Do not cut through the hinge.
As the felling gets close to the hinge, the tree should
begin to fall. If there is any chance that the tree may
not fall in desired direction or it may rock back and
bind the saw chain, stop cutting before the felling back
cut is complete and use wedges of wood, plastic or
aluminium to open the cut and drop the tree along the
desired line of fall.
When the tree begins to fall remove the chainsaw from
the cut, stop the motor, put the chainsaw down, then
use the retreat path planned. Be alert for overhead
limbs falling and watch your footing.

Removing buttress roots

See page 252.

A buttress root is a large root extending from the trunk of
the tree above the ground. Remove large buttress roots
prior to felling. Make the horizontal cut into the buttress

¿

 rst,

followed by the vertical cut. Remove the resulting loose
section from the work area. Follow the correct tree felling
procedure after you have removed the large buttress roots.

Bucking a log

See page 253.

Bucking is cutting a log into lengths. It is important to
make sure your footing is

¿

 rm and your weight is evenly

distributed on both feet. When possible, the log should be
raised and supported by the use of limbs, logs or chocks.
Follow the simple directions for easy cutting. When the log
is supported along its entire length, it is cut from the top
(overbuck).
When the log is supported on one end, cut 1/3 the diameter
from the underside (underbuck). Then make the

¿

 nished

cut by overbucking to meet the

¿

 rst cut.

When the log is supported on both ends, cut 1/3 the
diameter from the top (overbuck). Then make the

¿

 nished

cut by underbucking the lower 2/3 to meet the

¿

 rst cut.

When bucking on a slope always stand on the uphill side
of the log. When “cutting through”, to maintain complete
control release the cutting pressure near the end of the
cut without relaxing your grip on the chainsaw handles.
Don’t let the chain contact the ground. After completing the
cut, wait for the saw chain to stop before you move the
chainsaw. Always stop the motor before moving from tree
to tree.

Limbing a tree

See page 254.

Limbing is removing the branches from a fallen tree. When
limbing leave larger lower limbs to support the log off the
ground. Remove the small limbs in one cut. Branches
under tension should be cut from the bottom up to avoid
binding the chainsaw.

Cutting springpoles

See page 254.

A springpole is any log, branch, rooted stump, or sapling
which is bent under tension by other wood so that it springs
back if the wood holding it is cut or removed.
On a fallen tree, a rooted stump has a high potential of
springing back to the upright position during the bucking
cut to separate the log from the stump. Watch out for
springpoles—they are dangerous.

 WARNING

Springpoles are dangerous and could strike the operator,
causing the operator to lose control of the chainsaw.
This could result in severe or fatal injury to the operator.
This should be done by trained users.

RESIDUAL RISKS

Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise in use and the
operator should pay special attention to avoid the following:

Ŷ

Injury caused by vibration. Always use the right tool for
the job, use designated handles and restrict working
time and exposure.

Ŷ

Exposure to noise can cause hearing injury. Wear ear
protection and limit exposure

Ŷ

Contact with exposed saw teeth of the chain (cutting
hazards).

Ŷ

Unforeseen, abrupt movement or kickback of the guide
bar (cutting hazards).

Ŷ

Parts ejected from the saw chain (cutting/injection
hazards).

Ŷ

Thrown out pieces of the work piece (wood chips,
splinters)

Ŷ

Inhalation of saw dust and particles.

Ŷ

Skin contact with lubricant/oil.
