16

 | English

1 609 92A 2A0 | (17.11.16)

Bosch Power Tools

Safety Warnings for Drills



Wear ear protectors when impact drilling.

Exposure to

noise can cause hearing loss.



Use auxiliary handle(s), if supplied with the tool.

Loss

of control can cause personal injury.



Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord.

Cutting ac-

cessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electric shock.



Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



Switch off the power tool immediately when the tool
insert jams. Be prepared for high reaction torque that
can cause kickback.

The tool insert jams when:

– the power tool is subject to overload or
– it becomes wedged in the workpiece.



Application tools can become hot whilst working!
There is a risk of injury when changing the application
tool.

Use protective gloves to remove the application tool.



In order to prevent the power tool from being switched
on unintentionally, always unlock the lock-on button.

To do so, briefly press the On/Off switch.



When working with the machine, always hold it firmly
with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



Products sold in GB only:

 Your product is fitted with a

BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

Products sold in AUS and NZ only:

 Use a residual current

device (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

Intended Use

The machine is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal and plastic. Ma-
chines with electronic control and right/left rotation are also
suitable for screwdriving.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Keyless chuck

2

Spindle lock button  (

Universal

Impact 650,

Universal

Impact 700,

Universal

Impact 700 + Drill

Assistant)

3

“Drilling/Impact Drilling” selector switch

4

Rotational direction switch

5

Lock-on button for On/Off switch

6

On/Off switch

7

Thumbwheel for speed preselection

8

Drill Assistant unlocking button ***

9

Auxiliary handle with depth stop */***

10

Drill Assistant ***

11

Dust box ***

12

Dust box unlocking button (2x) ***

13

Dust collection device ***

14

Sealing ring ***

15

Dust protection ring ***

16

Clip of the dust collection device ***

17

Setting ring ***

18

Wing bolt for auxiliary handle fastening
Drill Assistant ***

19

Handle (insulated gripping surface)

20

Auxiliary handle (insulated gripping surface)

21

Wing bolt for auxiliary handle fastening *

22

Button for depth stop adjustment *

23

Depth stop *

24

Universal bit holder *

25

Screwdriver bit *

26

Mounting ***

27

Hex key **

28

Key type drill chuck

29

Chuck key

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

** Commercially available (not included in the delivery scope)

*** Standard delivery scope of UniversalImpact 700 + Drill Assis-
tant
