English

2

 En

Installing the speakers

Installing the front, center, and

surround speakers

Front speakers:

 Place the two front speakers on the

left and right sides of the TV, at approximately the
same height as the TV, facing directly forward.

Surround speakers:

 Place the left and right

surround speakers behind your listening position,
facing slightly inward, about 1.8 meters (approx. 6 ft.)
above the floor.
You can place the front and surround speakers on
tables or other supports, or mount them on the walls.
For more information, see “Wall-mounting the
speakers”.

Center speaker:

 Place the center speaker centrally

between the front speakers, facing directly forward.

Installing the subwoofer

Place the subwoofer on the outside of either the right
or the left front speaker, as shown in

A

 and

B

.

The placement shown in

C

 is also possible, however, if

the subwoofer is placed directly facing a wall and your
listening position is in the center of the room, you may
not be able to obtain enough bass sound from the
subwoofer. This is because “standing waves” are
forming between the two parallel walls and cancelling
out the bass sounds. In this case, position the
subwoofer at an angle to the wall. It may be necessary
to break up parallel wall surfaces by placing
bookshelves, etc., along them.

Wall-mounting the speakers

You can mount the speakers on the wall as follows.

1

Install screws into a solid wall or wall support
as shown below. Use 3.5 to 4 mm (1/8")
diameter self-tapping screws.

2

Hang each speaker by its keyhole slots onto
the protruding screws.

Note

• Make  sure the shaft of the screw is seated in the

narrow part of the keyhole slot. Otherwise, the
speaker may fall.

Warnings

• Each speaker weighs 0.45 kg (1 lbs.). Do not

mount the speakers on thin plywood or on a wall
with a soft surface material. Otherwise, the screws
may pull out of the surface and the speakers may
fall, possibly damaging the speakers or causing
personal injury.

• Do  not affix the speakers to a wall using nails,

adhesives, or unstable hardware. Long-term use
and vibration may cause the speakers to fall.

• To  avoid accidents resulting from tripping over

loose speaker cables, affix the cables to the wall.

• Mount the speakers in a wall location that will be

unlikely to result in injury to an individual’s head.

Subwoofer

Front speaker

A

B

C

Note: Standing waves
may make it difficult to
hear bass sounds here.

45 mm

(1-3/4")

Wall/wall
support

6 mm

(1/4")

Minimum

20 mm (3/4")
