EN

6

3 - User instructions

Installation

All operations relating to installation (electrical connection)

must be performed by qualified personnel in accordance with

the current regulations.

For specific instructions, see the section reserved for the installer

IMPORTANT

DO NOT LOOK AT THE LEDS AND DISPLAYS INTENSELY.

Functions

All functions can be performed using the ON/OFF button, the

display area and the “back” button. Information and feedback

are provided by the graphic display.

Touch Control on/offl

After applying power, the touch control takes a second to be

ready. After a reset, all the LEDs light up for one second. After

this time all the LEDs go off again. The interface can now be

started by touching the on/off button. The logo appears on the

display for 2 seconds, followed by a safety warning sign.  Do

not place hot pans on the display.

Display area

Button

ON/OFF

Button

“INDIETRO/BACK”

The cooking mode is then active. The display shows all the

cooking zones. The electronics will remain active for 20

seconds.

If no action is taken within this time (zone or timer selection),

the hob goes into standby, indicated by an acoustic signal.

The induction hob only switches on if the on/off button is

pressed. If another button is recognised, the hob will not turn

on.

Manual switching off of the hob takes place by keeping the

on/off key pressed.

Automatic switch off

The hob changes from switching on to switching off after 20

sec. if no cooking zone is activated or the multifunction button

is pressed during this time.

Switching a cooking zone on/off

If the control is already on, it is possible to select a zone

by touching one of the cooking zones on the display. After

selecting the cooking zones, the cooking level can be adjusted

by touching the slider area. By “sliding” your finger on the

slider area it is possible to increase or decrease the cooking

level (0 - P). Alternatively, the cooking level can be selected

directly on the slider without sliding. If the cooking level is set

to 0 the cooking zone is in “off” mode.

Switching off all the cooking zones

Immediate switching off of all the cooking zones is always

possible by pressing and holding the on/off key. Even if the

Touch Control is locked, switching off is possible. All cooking

zones that have the “hot” status have a circle with three rings.

Automatic switch-off (operating time limitation)

Depending on the cooking level chosen, a maximum operating

time limit is defined (if no cooking level changes are made).

If this maximum operating time is exceeded on a cooking

zone, it is switched off. If the surface is hot, the residual heat is

displayed. After each user operation, the time remaining until

automatic switch off is reset to the defined operating time limit

of this cooking level.

The timer settings have priority over the operating time

limitation. The detailed operating time according to the power

level can be ascertained from the table.
