EN

8

Cooking level

Power

level [%]

Operating

time [h]

0

0

0

1

3

6

2

6.5

6

3

11.0

5

4

15.5

5

5

19.0

4

6

31.5

1.5

7

45.0

1.5

8

64.5

1.5

9

100

1.5

Protection against involuntary activation

The Touch Control switches off automatically in the event of

an identified permanent use of the keys for approximately 10

seconds.

The Touch Control beeps for 10 seconds and the error code “E

R 0 3” flashes on the display.

If the malfunction exceeds 10 sec, only the error code “ER 03”

continues to flash during the malfunction time and is identified

as such. If the cooking zone is in the “hot” phase, the symbol

alternates with the error code.

(After cleaning the glass that covers the keys, all the keys are

ready for use in a short space of time).

If a cooking zone is not activated within 10 seconds after

pressing the on/off button, the Touch Control is returned to

standby mode.

Surface cleaning mode

To allow cleaning of the surface without inadvertently operating

the keys, there is a “lock” function. By pressing the “20s” key

the commands will be blocked and a counter will count the

20 sec.

Residual heat

The glass temperature of each cooking zone is calculated and

displayed by a circle symbol with three rings for each cooking

zone. The 3-ring icons will be displayed until the temperature

is below a safe temperature (~ 60°C).  The residual heat

indication is displayed for a maximum of approximately 50

minutes.

Automatic pan detection

Automatic pan detection allows the intuitive use of induction

hobs. The function automatically recognises the pans and

changes the position of the pans on the hob.

As soon as a pan is detected, the cooking zone is automatically

selected and the slider appears so that the user can easily set

the cooking level for this cooking zone.

Furthermore, it is possible to activate the semi-automatic bridge

function.

NOTE: during normal operation of the hob (excluding

operation with the Chef function active), if the pan is

moved by sliding it instead of lifting it, it may happen

that the pot presence sensors detect a large pot as if

they were 2 separate small pans.

To avoid this possibility of incorrect identification

of the pot, simply lift the pot for a few seconds and

then reposition it above the sensors so that it is again

recognized as a single area (for example bridge) and

then distribute the intensity of the power evenly.

If even this attempt does not lead to recognizing the

cooking area as a single area, lift the pot, then adjust

the cooking area settings to zero, then reposition the

pot and adjust the chosen power again.

Warning: if after these attempts the pot is still seen

as a separate cooking zone, it could depend on the

type of bottom of the pot. Then replace the pan with a

suitable one (see Containers on page 3)

ATTENTION

After use, turn off the hob elements using their command

without using the pan detector.

NOTE: the automatic pan presence detection system

generates a small “click” in the background cyclically
