FHMA 604 3G DC / FHMA 755 4G DC/DCL / FHMA 905 4G DCL / FHSM 604 3G DC

FHSM 604 4G / FHSM 755 4G DC / FHSM 905 4G DCL

– 6 –

EN

MODELS‘S CONFIGURATION

MOD.

nr

AUX

nr

SR

nr

R

nr

DC

N

burners

Heat

Source

Total

Rated

Capacity

G20

(m

3

/h)

Total

Rated

Capacity

G30/G31

(g/h)

Air

Neccessary

for

combustion

(m

3

/h)

Tot.

Installed

Gas

Rated

Power

(kW)

Tot.

Installed

LPG

Rated

Power

(kW)

Weight

(net - gross)

(kg)

FHSM 604 4G

1

2

1

4

GAS

0,713

545

15

7,5

7,5

8-9,4 (C)

l

7,1-8,5 (E)

FHSM 604 3G DC

1

2

1

4

GAS

0,742

567

15,6

7,8

7,8

8-9,4 (C)
7,1-8,5 (E)

FHSM 755 4G DC

1

2

1

1

5

GAS

1,028

785

21,6

10,8

10,8

10,5 -12(C)
8,9- 10,4 (E)

FHSM 905 4G DCL

1

2

1

1

5

GAS

1,028

785

21,6

10,8

10,8

14- 15,7 (C)
12,5 -14,2(E)

FHMA 604 3G DC

1

2

1

4

GAS

0,742

545

15,6

7,8

7,5

8,8-10,2 (C)

FHMA 755 4G DC

1

2

1

1

5

GAS

1,028

764

21,6

10,8

10,5

11,5 -13 (C)

FHMA 755 4G DCL

1

2

1

1

5

GAS

1,028

764

21,6

10,8

10,5

11,5 -13 (C)

FHMA 905 4G DCL

1

2

1

1

5

GAS

1,028

764

21,6

10,8

10,5

14,5 -16,2 (C)

DC = Double Crown SR-Semi-Rapid R = Rapid  AUX=Auxiliary C = Cast Iron Grid   E = Enameled Grid

Power supply = 220 -240 V; Frequency = 50 -60 Hz; Power/current = 0,6 Watt

INSTALLATION

Installation and electrical/gas

connection must only be carried out by

specialized and licensed personnel.

The manufacturer declines any liability for

injury to persons or damage to things due to

failure noncompliance with these provisions.

The gas connection must comply with the

regulations in force in the country at the time

of installation.

Z

Ensure that the device is connected

directly to the mains socket. Ensure that

no adapters, no multi-sockets and no

extension cables are used to connect

the device.

Cabinet requirements

This handbook refers to a class 3 built-in gas

hob and type Y for electric part.

The gas pipe must not come into contact with

the sides of any oven under the hob.

For fitted units, the components (plastic

materials and veneered wood) must be

assembled with heat-resistant adhesives (min.

100°C): Unsuitable materials and adhesives

can result in warping and detachment.

The Ventilation of rooms must be in compliance

with local regulation.

The kitchen element must allow sufficient room

for the electrical connections of the appliance.

Important:

 These devices are „Y“ type with

respect to the degree of protection against

the dangers of fire. The minimum distance

from the edge appliance is 150 mm for the

side wall, 50 mm for the rear and 700 mm

for any cabinets above it. The appliance is

recommended to be built into 40 mm thick

worktops. In case the dimensions are different,

eventual modifications have to be managed by

the technician.

Note:

 if a hood is installed above the hob,

for the distance to be respected refer to the

assembly instructions of the hood.
