34

GB

2.  Divide the line into two equal parts (Fig. 20.3)

and then load the trimmer head by turning the
knob (Fig. 20.4).

WARNING!  –  Always  wear  protective

gloves during maintenance operations. Do not

carry out maintenance with the engine hot.

AIR FILTER

Every  8-10  working  hours,  remove  the  cover  (A,
Fig. 23), clean the filter (C).

BC  22  -  220:

  Clean  with  Emak  degreaser  p/n

001101009,  rinse  with  water  and  blast  dry  with
compressed air.

BC  24  -  240:

Clean  with  Emak  degreaser  p/n

001101009A, rinse with water and blast dry with
compressed air, not too close, blowing from the
inside outwards.
Replace  if  dirty  or  damaged.  The  engine  runs
irregularly if the filter is clogged, with consequent
higher consumption and lower performance.

FUEL TANK

Check fuel filter periodically. A dirty filter can cause
difficult starting and lower engine performance.
To clean filter proceed as follows: remove it from
fuel filling hole. Replace it (Fig. 22) if too dirty.

ENGINE

Clean  cylinder  fins  with  a  brush  or  compressed
air periodically. Dangerous overheating of engine
may occur due to impurities on the cylinder.

SPARK PLUG

Clean  spark  plug  and  check  electrode  distance
periodically (Fig. 24). Use Champion NGK CMR7H
or of other brand with the same thermal grade.

GEAR HOUSING

Every 30 working hours, remove screw (D, Fig. 8)
on  the  gear  housing  and  check  the  quantity  of
grease. Do not use more than 10 grams. Use high
quality molybdenum bisulfide grease.

Never use fuel for cleaning operations.

CARBURETOR

Before adjusting the carburetor, clean the air filter

BLADE SHARPENING (2-3-4 TOOTH)

1.  Blades  are  reversible:  when  one  side  is  no

longer  sharp,  the  blade  can  be  turned  over

and used on the other side (Fig. 17).

2.  Blades  are  sharpened  using  a  flat  single-cut

file (Fig. 17).

3.  To maintain the correct balance, file all cutting

edges uniformly.

4.  If the blades are not sharpened correctly, this

can set up abnormal vibrations in the machine

and  cause  the  blades  themselves  to  break

ultimately.

BLADE SHARPENING (8 TOOTH)

Always check the general condition of the blade.

Correct  sharpening  permits  the  maximum

performance of the brush cutter. To sharpen the

teeth, use a file or grindstone and proceed with

light  touches,  respecting  the  corners  and  the

dimensions shown in Fig. 11A.

WARNING!  –

The  wrong  type  of  cutter  or

an incorrectly sharpened blade will increase the

risk  of  kickback.  Check  mower  blades  for

deterioration or cracks, and replace if damaged.

WARNING:  Never  repair  damaged

cutting

attachments

by

welding,

straightening  or  modifying  the  shape.  This

may  cause  parts  of  the  cutting  tool  to  come

off and result in serious or fatal injuries.

NYLON LINE HEAD

Only use line of the same diameter as the original

to avoid overloading the engine (Fig. 18).

In order to get more line out of the cutting head,

tap it lightly on the ground while working.

Note:

 Never hit the nylon head against hard spots

such as concrete or stones, it could be dangerous.

Replacing  the  nylon  line  on  the  LOAD&GO

trimmer head (Fig.20)

BC 22 S – BC 22 T - BC 220 S - BC 220 T (Ø 110

mm):

cut 4 m of nylon line Ø 2.4 mm.

BC 24 S – BC 24 T - BC 240 S - BC 240 T (Ø 130

mm):

cut 8.5 m of nylon line Ø 2.4 mm.

1.  Align  the  arrows  and  insert  the  line  into  the

trimmer head (Fig. 20.1) until it is released from

the opposite side (Fig.20.2).
