25

GB

2. SYMBOLS AND SAFETY WARNINGS (Fig.25)

1   -  Read  operator’s  instruction  book  before

operating this machine.

2   -  Wear head, eye and ear protection.
3   -  Wear strong boots and gloves when cutting

with metal or plastic blades.

4   -  Be aware that objects can be thrown.
5   -  Keep bystanders away 15 m.
6   -  Do  not  use  the  brushcutter  with  the  wood

cutting disk.

7   -  Warning! Kickback it’s danger.
8   -  On machines with a bent drive shaft it is not

possible to fit disks, only line heads.

9  -  Type of machine:

BRUSH CUTTER

.

10 -   Guaranteed sound power level.
11 -   CE conformity marking.
12 -   Serial number.
13 -  Year of manufacture.
14 -  Max. speed of output shaft, RPM

3. MAIN COMPONENTS (Fig.1)

  4  - Harness
  5  - Bevel gear
  6  - Curved guard
  7  - Nylon line head
  8  - Fuel tank cap
  9  - Purge Bulb
 10  - Carburettor adjustment screws
 11  - Muffler guard
 12  - Spark plug
 13  - Air filter
 14  - Starter Handle
 15  - Choke Lever
16   - Throttle trigger lockout
 17  - STOP button
18   - Throttle lever
19   - Harness attachment
 20  - Handle
 21  - Shaft arm

4. ASSEMBLY

FITTING THE NYLON LINE HEAD (Fig. 8)

Put the upper (F) flange in place. Put the head fixing
pin (H)  in the appropriate hole (L) and tighten the
head (N) anti-clockwise by hand.

FITTING THE HANDLE (Figs. 2)

Fit  the  handle  onto  the  shaft  arm  and  secure  it

using screws (A). The handle position is calculated
depending on the requirements of the operator.

ASSEMBLING THE SAFETY BOOM (Fig. 9A)

When using the disc instead of nylon line head, it
is necessary to set up the “safety boom”. Fix the
boom (A) under the attachment (C) of handle (20B,
Fig. 1) by means of the screws (B). Taking care to
verify the “safety boom” being on the left side of
the brushcutter.

Assembling the bike handle

BC 220 T (Figs. 4)

-  Place the bike handle (A, Fig.4) in the lower hub

(B1).

CAUTION:  The  bike  handle  (A)  must  be

fixed onto the hub (B) inside the two notches

(C) indicated on the bike handle.

-  Place the upper hub (B2) in position and tighten

the 4 screws (D), without finally tighten yet.

-  Line  up  the  handlebar  at  a  right  angle  to  the

drive tube.

-  Tighten down the screws (D) firmly.

BC 240 T (swivelling bike handle)

-  Release the wing screw (E, Fig.5) and unscrew

it until the bike handle (F) can be turned anti-
clockwise.

-  Turn  the  handlebar  90°  and  then  swing  the

handles up.

-  Tighten down the wing screw (E) firmly.

Storage or transportation positions

-  Reverse  the  sequence  described  above  to

swing the handles up and turn the bike handle
clockwise.

Mounting the control handles (BC 220 T – BC

240 T) (Figs. 6)

-  Loosen the screw (G, Fig.6). The nut (H) remains

in the control handle (L).

-  Push the control handle (L) (throttle trigger M

must point toward the gearbox) onto the bike
handle (N) so that the holes (P) line up.

-  Insert screw (G) and tighten down firmly.
