GB

- 24 -

Sound and vibration

L

pA

 sound pressure level ..................... 96,1 dB(A)

K

pA

 uncertainty .............................................. 3 dB

L

WA

 sound power level .......................... 113 dB(A)

Wear ear-mu

ff

 s.

The impact of noise can cause damage to hea-

ring.

In operation

Vibration emission value a

h

 = 4 m/s

2

K uncertainty = 1.5 m/s

2

Reduce noise generation and vibration to a

minimum!

•

Use only equipment that is in perfect condi-

tion.

•

Maintain and clean the equipment regularly.

•

Adopt your way of working to the equipment.

•

Do not overload the equipment.

•

Have the equipment checked if necessary.

•

Switch off the equipment when not in use.

•

Wear gloves.

•

 Wear eye and hearing protection

5. Assembly

5.1 Mounting the blade guard hood

Important: The cutting blade guard hood must be

fi

 tted if you wish to work with the cutting blade.

The guard hood for the cutting blade must be ins-

talled as shown in Figures 10-11.

5.2 Joining the drive rod mechanism to the

connecting piece (Fig. 4-7)

Fit the handle screw (Item 10) as shown in Fig.

4. Open the handle screw and push the drive rod

mechanism (Item 4) into the connecting piece

(Item 5). Make sure that the centering lever (Item

R) latches in the guide hole (Fig. 5/Item H). Tigh-

ten the handle screw.

To take apart, undo the handle screw. Unlock the

centering lever and simultaneously pull the drive

rod mechanism out of the connecting piece.

5.3 Fitting / Replacing the cutting blade

The procedure for

fi

 tting the cutting blade is

shown in Figures 12-18. To dismantle, proceed in

reverse order.

•

Fit the carrier plate 30) onto the spline shaft

(Fig. 13)

•

Secure the cutting blade (1) on the carrier

plate (Fig. 14)

•

Place the pressure plate (31) over the thread

of the spline shaft (Fig. 15)

•

Plug on the cover of the pressure plate (32)

(Fig. 16)

•

Mount the nut (24) hand-tight (Fig. 17).

•

While pressing the locking lever (A), turn on

the nut until the carrier plate is held in posi-

tion. Tighten the nut with a suitable tool (Fig.

18).

Important: Left-hand thread!

•

Check whether the blade (1) can rotate freely

after you let go of the locking lever. If this is

not the case, have the mechanism checked

by an expert.

5.4 Fitting the cutting line guard hood to the

blade guard hood

Important: The cutting line guard hood must be

fi

 tted in addition if you want to work with the cut-

ting line.

The procedure for

fi

 tting the guard hood for the

cutting line is shown in Figures 19-20. A blade

(Fig. 19/ Item F) on the underside of the guard

hood automatically cuts the cutting line to the

optimum length. It is covered by a guard (Fig.

19/Item G). Remove the guard before you start

working and replace it when you have

fi

 nished

working.

5.5 Fitting the handle

Fit the handle as shown in Fig. 8-9.

5.6 Fitting / replacing the line spool

Fit the carrier plate (30) onto the spline shaft (Fig.

13)

While pressing the locking lever (A), turn on the

line spool until the carrier plate is held in position.

Tighten the line spool by hand (Fig. 21). Impor-

tant: Left-hand thread!

Check whether the line spool (3) can rotate freely

after you let go of the locking lever. If this is not

the case, have the mechanism checked by an

expert.
