Toshiba 43UA2063DG - Инструкция по эксплуатации - Страница 25

English

   - 24 -

format your Disk and specify the storage space that

will be used for timeshift function. When the setup is

completed result will be displayed. Press

Exit

 button.

Timeshift function will not be available for radio

broadcasts.

Disk Format

W h e n   u s i n g   a   n e w   U S B   s t o r a g e   d e v i c e ,   i t   i s

recommended that you first format it using the

Format

option in the

Record>Device Info

 menu in Live TV

mode. Highlight the connected device on the

Device

Info

 screen and press

OK

 or Right directional button

to see the list of available options. Then highlight

Format

 and press

OK

  to  proceed.  A  confirmation

dialogue will be displayed. Highlight

Yes

 and press

OK

 to start formatting.

IMPORTANT:

 Formatting your USB storage device

will erase ALL the data on it and it’s file system will be

converted to FAT32. In most cases operation errors will

be fixed after a format but you will lose ALL your data.

Schedule List

You can add reminders or record timers using the

Schedule List

 menu. You can access the

Schedule

List

 from the

Record

 menu in Live TV mode. Highlight

Schedule List

 and press

OK

. Previously set timers

will be listed if any available.
Press

Record

button to add a timer while the

Schedule

List

 menu is displayed on the screen. You can

define the type of the timer by setting the

Schedule

Type

 option as

Reminder

 or

Record

. When other

parameters are set highlight

Add

 and press

OK

. The

timer will be added to the list.
If any available, you can also edit or delete the timers

on this list. Highlight the timer of your choice and press

OK

.

Edit

 and

Delete

 options will appear at the bottom

of the screen. Highlight the desired option and press

OK

. After you edited a timer you can choose either

to replace it or add it as a new timer. If you choose

the Replace option, the timer will be saved with the

new settings. If you choose the

Add

 option, the timer

will be added to the list as a new timer. Highlight

Replace

 or

Add

 according to your preference and

press

OK

 to proceed. When you choose to delete

a  timer  a  confirmation  dialogue  will  be  displayed  on

the screen. Highlight

Yes

 and press

OK

 to delete the

selected timer.
A warning message will be displayed if the time

intervals of two timers overlap. You can not set more

than one timer for the same time interval.
Press

EXIT

 button to close the Schedule List.

CEC

With CEC function of your TV you can operate a

connected device with the TV remote control. This

function uses HDMI CEC (Consumer Electronics

Control) to communicate with the connected devices.

Devices must support HDMI CEC and must be

connected with an HDMI connection.
The TV comes CEC function switched on. Make

sure that all CEC settings are properly set up on the

connected CEC device. The CEC functionality has

different  names  on  different  brands.  CEC  function

might not work with all devices. If you connect a device

with HDMI CEC support to your TV, the related HDMI

input source will be renamed with the connected

device's name.
To operate the connected CEC device, select the

related HDMI input source from the

Inputs

 menu on

the Home Screen. Or press the

Source

 button if the TV

is in Live TV mode and select the related HDMI input

source from the list. To terminate this operation and

control the TV via the remote again, press the

Source

button, which will still be functional, on the remote and

switch to another source.
The TV remote is automatically able to control the

device once the connected HDMI source has been

selected. However not all buttons will be forwarded

to the device. Only devices that support CEC Remote

Control function will respond to the TV remote control.
The TV supports also ARC(Audio Return Channel)

feature. This feature is an audio link meant to replace

other cables between the TV and the audio system

(A/V receiver or speaker system). Connect the audio

system to the HDMI2 input on the TV to enable ARC

feature.
In order to activate ARC feature the

Speakers

 option

should be set as

External Audio System

. You can

access this option from the

TV options

 or

TV options>-

Settings>Device Preferences>Sound

 menu in Live TV

mode or from

Settings>Device Preferences>Sound

menu on the Home Screen. When ARC is active, TV will

mute its other audio outputs automatically. So you will

hear audio from connected audio device only (same

as other optical or co-axial digital audio outputs). The

volume control buttons of the remote will be directed

to connected audio device and you will be able to

control the volume of the connected device with your

TV remote.

Note:

 ARC is supported only via the HDMI2 input.

The CEC functions are set to

On

 by default. To switch

off completely do the following:

1 - Enter the

Settings>Device

Preferences>Inputs

menu on the Home Screen or

TV options>Set-

tings>Device Preferences>Inputs

 menu in Live TV

mode.
