English

   - 10 -

Standby Button

Press and hold the

Standby

button on the remote

control.

Power off

 dialogue will appear on the screen.

Highlight

OK

 and press the

OK

 button. The TV will

switch  into  standby  mode.  Press  briefly  and  release

to switch the TV into quick standby mode or to switch

on the TV when in quick standby or standby mode.

Inserting the Batteries into the Remote

Remove the screw that secure the battery compartment

cover on the back side of the remote control first. Lift

the cover gently. Insert two 1.5V - size

AAA

 batteries.

Make sure the (+) and (-) signs match (observe correct

polarity). Do not mix old and new batteries. Replace

only with same or equivalent type. Place the cover back

on. Then screw the cover back on again.

To pair remote with the TV

When TV is turned on for the first time, a search for

accessories will be performed before the initial setup

starts. You will need to pair your remote control with

your TV at this point.
Press and hold the

Source

 button on the remote for

about 5 seconds, the LED on the remote will light up.

Then release the

Source

 button, the LED will start

to blink. That means the remote is in pairing mode.

Now you will wait the TV to find your remote. Select the

name of your remote and press

OK

when it appears

on the TV screen.
When the paring process was successful, the LED

on  the  remote  will  go  off.  If  the  pairing  process  fails

the remote will enter to sleep mode after 30 seconds.

Initial Setup Wizard

Note:

Follow the on-screen instructions to complete the initial

setup process. Use the directional buttons and the

OK

 button

on the remote to select, set, confirm and proceed.

When turned on for the first time, a search for acces

-

sories will be performed before the initial setup starts.

Follow the on-screen instructions to pair your remote

control (depends on the model of the remote control)

and other wireless accessories with your TV. Press

Back/Return

 button to end adding accessories and

start the setup.

1. Welcome Message and Language Selection

“

Welcome

” message will be displayed along with

the language selection options listed on the screen.

Select the desired language from the list and press

OK

 to continue.

2. Quick Setup

If you didn’t priorly connect your TV to the internet via

Ethernet a screen will be displayed where you can

transfer your Android phone’s WLAN network and

Google Account to your TV. Highlight

Continue

 and

press

OK

 to proceed. Follow the on-screen instructions

on your TV and your phone to complete the process.

You can also skip this step by selecting

Skip

 option.

Some steps may be skipped depending on the settings

made in this step.
If you did priorly connect your TV to the internet via

Ethernet a message will be displayed stating that you

are connected. You can choose to continue with wired

connection or change the network. Highlight

Change

network

 and press

OK

 if you want to use wireless

connection instead of wired connection.

3. Network Connection

You will be directed to the next step automatically, if you

connect your TV to internet via Ethernet at this point. If

not, available wireless networks will be searched and

listed on the next screen. Select your WLAN network

from the list and press

OK

 to connect. Enter the

password using the virtual keyboard if the network is

password protected. Select the

Other network

 option

from the list, if the network that you want to connect

has hidden SSID.
If you prefer not to connect to the internet at this point

you can skip this step by selecting

Skip

 option. You

can connect to internet later using the

Network &

Internet

menu options in the

Settings

 menu from

the Home Screen or from the

TV options

 menu in

Live TV mode.
This step will be skipped if internet connection has

been established in the previous step.

4. Sign in to your Google account

If connection succeeds, you can sign in to your Google

account on the next screen. You need to be signed in

to a Google account in order to use Google services.

This step will be skipped if no internet connection has

been established in the previous step or if you already

signed in to your Google account in Quick Setup step.
By signing in, you will be able to discover new

apps for videos, music and games on Google Play;

get personalised recommendations from apps like

YouTube; buy or rent the newest movies and shows on

Google Play Movies & TV; access your entertainment

and control your media. Highlight

Sign In

 and press

OK

 to proceed. Sign-in options are as following:

•  Use your phone or computer:

 You can use a

browser on your phone or computer to sign in.

Highlight this option and press

OK

 button. A code

will be displayed on the TV screen. Make sure your

phone or computer is on the same network as your

TV. Open the given website (androidtv.com/setup,

follow on-screen instructions for the up-to-date

website url) in your phone’s or computer’s browser

and enter the code you see on your TV screen into

the  related  entry  field. Then  follow  the  instructions

on your device and complete the process.

•  Use your remote:

 Using this option you can sign in to

your Google account by entering your e-mail address

or phone number and your password.
