20

21

BE 650R

SBE 600R

SBE 650R

SB2-650

......... 650 W ..............600 W ............. 650 W ................650 W

......... 325 W ..............315 W ............. 325 W ................325 W

....0-3000 min

-1

 .... 0-2900 min

-1

 .... 0-3000 min

-1

 2250/3000 min

-1

....... 1500 min

-1

 ........1300 min

-1

 ....... 1300 min

-1

 ..850/1300 min

-1

..............- min

-1

 ......22500 min

-1

 ..... 22500 min

-1

 .......22500 min

-1

........... 25 Nm ..............23 Nm ............. 25 Nm ...............25 Nm

..............- ....................15 mm ............. 16 mm ...............16 mm

..............- ....................20 mm ............. 20 mm ...............20 mm

........... 10 mm..............13 mm ............. 13 mm ...............13 mm

........... 30 mm..............30 mm ............. 30 mm ...............30 mm

.....1,0-10 mm....... 1,5-13 mm ....... 1,5-13 mm ........ 1,5-13 mm

...1/2"x20 ............1/2"x20  ........... 1/2"x20  .............1/2"x20

........... 43 mm..............43 mm ............. 43 mm ...............43 mm

.......... 1,7 kg ...............1,8 kg .............. 1,8 kg ................1,8 kg

........... 83 dB (A) .........83 dB (A)......... 83 dB (A) ...........83 dB (A)

........... 94 dB (A) .........94 dB (A)......... 94 dB (A) ...........94 dB (A)

..............- ..................102 dB (A)....... 102 dB (A) .........102 dB (A)

..............- .................. 113 dB (A)........113 dB (A) ......... 113 dB (A)

..............- .................20,5 m/s

2

 ......... 20,5 m/s

2

 ...........20,5 m/s

2

..............- ...................1,5 m/s

2

 ........... 1,5 m/s

2

 .............1,5 m/s

2

.......... 3,5 m/s

2

 ............3,5 m/s

2

 ........... 3,5 m/s

2

 .............3,5 m/s

2

.......... 1,5 m/s

2

 ............1,5 m/s

2

 ........... 1,5 m/s

2

 .............1,5 m/s

2

.......< 2,5 m/s

2

 .........< 2,5 m/s

2

 ........ < 2,5 m/s

2

 ..........< 2,5 m/s

2

.......... 1,5 m/s

2

 ............1,5 m/s

2

 ........... 1,5 m/s

2

 .............1,5 m/s

2

ENGLISH

SPECIFIED CONDITIONS OF USE

BE650R:

 This power tool is intended to be used for drilling

in wood, metal, plastics and screwdriving.

SB2-650:

 This power tool is intended to be used for drilling,

percussing drilling.

SBE600R, SBE650R:

This power tool is intended to be

used for drilling, percussion drilling and screwdriving.
Do not use this product in any other way as stated for

normal use.

MAINS CONNECTION

Connect only to single-phase a.c. current and only to the

system voltage indicated on the rating plate. It is also

possible to connect to sockets without an earthing contact

as the design conforms to safety class

II

.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that this product is

in conformity with the following standards or standardized

documents. EN 60745, EN 55014-1, EN 55014-2,

EN 61000-3-2, EN 61000-3-3, in accordance with the

regulations 2006/42/EC, 2004/108/EC

Winnenden, 2011-01-04

Rainer Kumpf

Manager Product Development
Authorized to compile the technical ile

MAINTENANCE

The ventilation slots of the machine must be kept clear at all

times.
If the machine is mainly used for percussion drilling,

regularly remove collected dust from the chuck. To remove

the dust hold the machine with the chuck facing down

vertically, and completely open and close the chuck. The

collected dust will fall from the chuck. It is recommended to

regularly use cleaner  for the clamping jaws and the

clamping jaw borings.
Use only AEG accessories and AEG spare parts. Should

components need to be replaced which have not been

described, please contact one of our AEG service agents

(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.

Please state the ten-digit No. as well as the machine type

printed on the label and order the drawing at your local

service agents or directly at: AEG Electric Tools,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

SYMBOLS

Please read the instructions carefully before

starting the machine.

Always disconnect the plug from the socket

before carrying out any work on the

machine.

Accessory - Not included in standard

equipment, available as an accessory.

Do not dispose of electric tools together

with household waste material! In

observance of European Directive 2002/96/

EC on waste electrical and electronic

equipment and its implementation in

accordance with national law, electric tools

that have reached the end of their life must

be collected separately and returned to an

environmentally compatible recycling

facility.

Class II construction, tool in which

protection against electric shock does not

rely on basic insulation only, but in which

additional safety precautions, such as

double insulation or reinforced insulation,

are provided.

ENGLISH

TECHNICAL DATA

Percussion Drill/Screwdriver

Rated input ..............................................................................

Output ......................................................................................

No-load speed .........................................................................

Speed under load max. ...........................................................

Rate of percussion under load max .........................................

Static stall torque*, 1

st

 gear ......................................................

Drilling capacity in concrete .....................................................

Drilling capacity in brick and tile ..............................................

Drilling capacity in steel ...........................................................

Drilling capacity in wood ..........................................................

Drill chuck range ......................................................................

Spindle thread .........................................................................

Chuck neck diameter ...............................................................

Weight according EPTA-Procedure 01/2003 ...........................

* Measured according to AEG standard N877318

Noise information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

As drill/screwdriver

  Sound pressure level (K = 3 dB(A)) .......................................

  Sound power level (K = 3 dB(A)) ............................................

As impact drill

  Sound pressure level (K = 3 dB(A)) .......................................

  Sound power level (K = 3 dB(A)) ............................................

Wear ear protectors!
Vibration information

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

Vibration emission value a

h

:

  Percussion drilling into concrete ...........................................

  Uncertainty K ........................................................................

  Drilling into metal ..................................................................

  Uncertainty K ........................................................................

  Screwdriving .........................................................................

  Uncertainty K ........................................................................

 WARNING! Read all safety warnings and all

instructions, including those given in the accompanying

brochure

. Failure to follow the warnings and instructions

may result in electric shock, ire and/or serious injury.

Save all warnings and instructions for future reference.

SAFETY INSTRUCTIONS

Drill safety warnings:
Wear ear protectors when impact drilling.

Exposure to

noise can cause hearing loss.

Use auxiliary handle(s), if supplied with the tool.

Loss of

control can cause personal injury.

Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory

may contact hidden wiring or its own cord.

Cutting

accessory contacting a „live“ wire may make exposed metal

parts of the power tool „live“ and could give the operator an

electric shock.

Screwdriver safety warnings:
Hold power tool by insulated gripping surfaces, when

performing an operation where the fastener may

contact hidden wiring.

Fasteners contacting a "live" wire

may make exposed metal parts of the power tool "live" and

could give the operator an electric shock.

Additional safety warnings:

Appliances used at many different locations including open

air should be connected via a residual current device of

30 mA or less.
Always wear goggles when using the machine. It is

recommended to wear gloves, sturdy non slipping shoes

and apron.
Sawdust and splinters must not be removed while the

machine is running.
Always disconnect the plug from the socket before carrying

out any work on the machine.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.

Always lead the cable away behind you.
When working with large drill diameters, the auxiliary handle

must be fastened in a right angle with the main handle (see

illustrations, section Twisting the handle).
When working in walls ceiling, or loor, take care to avoid

electric cables and gas or waterpipes.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may signiicantly increase

the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may signiicantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.
