16

 | English

2 610 017 516 | (3.11.11)

Bosch Power Tools

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1

On/Off switch

2

Plug for vacuum connection

3

Auxiliary handle (insulated gripping surface)

4

Protection guard with quick clamp

5

Spindle lock button

6

Holder for vacuum hose

7

Handle (insulated gripping surface)

8

Clamping lever for protection guard

9

Grinder spindle

10

Mounting flange with O-ring

11

Diamond cutting disc *

12

Clamping nut

13

Two-pin spanner for clamping nut

14

Quick-clamping nut

*

15

Index mark *

16

Dry diamond core bit *

17

Open-end spanner, size 19 mm *

18

Vacuum hose

19

Elbow

20

Vacuum connection

21

Extraction adapter

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Noise/Vibration Information

Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:

Sound pressure level 100 dB(A); Sound power level

111 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:

Cutting tiles (50 mm): a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

.

The vibration emission level given in this information sheet

has been measured in accordance with a standardised test

given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of expo-

sure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working pe-

riod.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep hands warm, organise work patterns.

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with the fol-

lowing standards or standardization documents: EN 60745

according to the provisions of the directives 2011/65/EU,

2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:

Robert Bosch GmbH, PT/ETM9,

D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

13.10.2011

Assembly

Mounting the Protective Devices

f

Before any work on the machine itself, pull the mains

plug.

Note:

After breakage of the grinding disc during operation or

damage to the holding fixtures on the protection guard/power

tool, the machine must promptly be sent to an after-sales

service agent for maintenance for addresses, see section “Af-

ter-sales Service and Customer Assistance”.

Cut-off Grinder

GCT 115

Professional

Article number

3 601 C91 0..

Rated power input

W

720

No-load speed

min

-1

11 000

Max. diameter for diamond cutting

discs

mm

115

Cutting discs width, min.

mm

1

Cutting discs width, max.

mm

3

Mounting bore

mm

22.2

Thread of grinder spindle

M 14

Thread length (max.) of grinder

spindle

mm

22

Weight according to

EPTA-Procedure 01/2003

kg

1.9

Protection class

/

II

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.

Dr. Egbert Schneider

Senior Vice President

Engineering

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI
