17 ENGLISH

 lamp flashes

4 times for each

sequence

•  Threads and hairs are tangled with the

drive wheels.

  Remove them from the drive wheels

(Fig. M-2).

•  The Robotic Cleaner passed through

a confined area where its top surface

was pushed down.

  This is not a malfunction.

 lamp flashes 5

or 7 times for each

sequence

•  The Robotic Cleaner has overheated.

  Turn the Robotic Cleaner OFF,

remove the battery cartridge(s), and

wait for an hour. Use the Robotic

Cleaner only at room temperatures

not exceeding 40°C (104°F).

 and

lamps flash once

for each sequence

•  The dust box or the filter has not been

installed.

  Install the dust box or the filter.

 and

all   lamps flash

once for each

sequence

•  The remaining battery charge was

not enough (

 or

) to start

cleaning.

  Fully charge the battery cartridges.

 and   lamps

light up

•  Threads and hairs are tangled in the

drive wheels.

  Remove them from the drive wheels

(Fig. M-2).

•  The Robotic Cleaner passed through

a confined area where its top surface

was pushed down.

  This is not a malfunction.

 and   lamps

light up

•  A sensor error has occurred.

  Turn the Robotic Cleaner OFF and

then ON.

 and   lamps

light up

•  An error has occurred in the Robotic

Cleaner.

  Turn the Robotic Cleaner OFF and

then ON.

 lamp flashes

once for each

sequence

•  Threads and hairs are tangled in the

side brushes and main brush.

  Remove them from the brushes (Figs.

A, N-3).

 lamp

lights up

•  The dust box is full of dust and dirt or

the filter is clogged.

  Empty the dust box (Fig. K-2) and

clean the filter (Fig. K-5).

TROUBLESHOOTING

NOTE: If the problem persists after the remedial

action is taken, consult your nearest Makita Service

Center.

Symptom

Cause/Remedy

The lamps do

not light up

when you press

the   button.
The Robotic

Cleaner does not

operate when you

press the button

on the Robotic

Cleaner or the

remote control.

  Install the battery cartridges correctly.

  Fully charge the battery cartridges.

  Press the   button to turn the

Robotic Cleaner ON.

The Robotic

Cleaner does not

operate.

  If the

 Troubleshooting

lamp,

 Filter maintenance lamp,

or

 Brush maintenance lamp lights

up or flashes, see “RESTORING THE

ROBOTIC CLEANER” to resolve the

problem.

  If the pilot lamp flashes slowly, press

and hold the   POWER button on

the Robotic Cleaner until all indicators

go off, or press the   POWER OFF

button on the remote control to clear

the timer.

The Robotic

Cleaner starts

operation

automatically.

•  The auto-on timer has been activated.

The Robotic

Cleaner stops

operation during

cleaning.

  Turn the Robotic Cleaner OFF, and

then remove any cords, strings, etc.

from the drive wheels.

  If the Robotic Cleaner has gotten

stuck on a barrier or other obstacle,

move the Robotic Cleaner to a

different location.

The cruising speed

is not constant.

•  If an obstacle is detected, the Robotic

Cleaner will slow down as it takes time

to calculate a traveling direction. This

is not a malfunction of the Robotic

Cleaner.

The Robotic

Cleaner does not

travel straight

forward.

  Turn the Robotic Cleaner OFF, and

then remove any foreign objects

tangled in the drive wheels.

  Clean the ultrasonic sensors.

The Robotic

Cleaner is hitting

obstacles more

frequently than

before.

  Clean the ultrasonic sensors.

The Robotic

Cleaner falls down

stairs or to a lower

floor.

  Clean the cliff sensors.

•  The Robotic Cleaner may not avoid

differences in level of 5.5 cm or

less. This is not a malfunction of the

Robotic Cleaner.

The operating

sound is louder

than usual.

  Empty the dust box and clean the

filter, the side brushes, and the main

brush.
