8

Natural Gas
The natural gas regulator supplied must be fitted for natural gas. Ensure the arrow on the regulator points
towards the direction of the gas flow. Commissioning Procedure - The test point pressure must be adjusted
to 1.00 kPa with the Outer Wok Burner or both Semi Rapid Burners operating on maximum flame.

Propane (LPG)
Fit the LPG test point assembly (supplied in the gas conversion kit). An Australian Approved gas regulator
suitable for a supply pressure of 2.75kPa should be part of the gas tank supply.

Electrical connection      The electric connection must comply with the current legal standards and

regulations.
Before making the connection, check that:
- The system electrical rating and the current outlets are adequate for the maximum
power output of the appliance (see the rating plate applied to back of the cooker).
- The outlet or the system is equipped with an efficient ground connection in
accordance with the current legal standards and regulations. The company will not
be responsible for the non-compliance with these instructions.

                                       letter L (phase)

 = brown wire;

                                       letter N (neutral)

 = blue wire;

                                       ground symbol

 = green-yellow wire;

- The power cord must be positioned so that an over temperature of 75 K will not be
reached at any point.
- It is necessary to allow disconnection of the appliance from the supply after
installation. The disconnection can be achieved by having a plug accessible or by
incorporating a switch in the fixed wiring in accordance with the wiring rules.
- Do not use reductions, adapters or splitters since they might cause false contacts
and lead to dangerous overheating.
When the connection is made directly to the electric network:
- Use a device that ensures disconnection from the mains in which the contacts are
opened to a distance that permits complete disconnection according to the
conditions for over-voltage category III.
- Remember that the ground wire must not be interrupted by the circuit-breaker.
- As an alternative, the electric connection can also be protected by a high-sensitivity
residual current circuit-breaker.
- It is highly recommended to attach the special green-yellow ground wire to an
efficient ground system.
WARNING: If the power cord is replaced, the ground wire (yellow-green) connected
to the terminal, should be longer than the other wires by about 2 cm.
WARNING: The  power cord should be replaced only by qualified personnel.

Types of power cords  Some appliances are supplied fitted with a 15A cord and plug.  All other appliances

are equipped with a terminal for the electric connection placed behind, which is
accessible by removing the posterior casing. The size of the supply cord to be used:


Operation at 220-240V~ : use a H05BB-F three-wire cable (cable 3x2,5 mm²)
Operation at 380-415V2N~ : use a H05RR-F o H07RN-F  four-wire cable (cable 4x1,5 mm²)
Operation at 380-415V3N~ : use a H05RR-F o H07RN-F five-wire cable (cable 5x1,5 mm²)


Ensure that the electricity supply is switched off before making the connection. This
appliance must be earthed. Connection to the supply must be made through fixed
wiring. It cannot be connected to a normal domestic power socket.

If this cooker is to be connected to a new or upgraded electrical installation, then it
must be connected to the supply by a supply cord fitted with an appropriately rated
plug that is compatible with the socket outlet fitted to the final sub-circuit in the fixed
wiring that supplies this cooker or an appropriately rated installation male connector
that is compatible with the installation female connector fitted to the final sub-circuit
in the fixed wiring that supplies this cooker.
.
