17

INDUCTION

Fig 17

Functions

1…9 :

Power Level

     P :

  Booster

     A :

Heating Accelerator

Hob control knob

These knobs provide control of the ceramic hob's cooking zones.

The zone it controls is shown above each knob. Turn the knob to the right to set the
zone's operating power; the settings range from a minimum of 1 to a maximum of 9.
The working power is shown by a display on the hob.

Heating accelerator

Each cooking zone is equipped with a heating accelerator.

This system allows the zone to be operated at peak power for a time proportional to
the heating power selected.
To start the heating accelerator, turn the knob to the left, select setting "A" and then
release. The letter "A" will appear on the display on the hob.
You now have 3 seconds to select the heating setting of your choice. Once a setting
between 1 and 9 has been selected, "A" and the chosen setting will flash in
alternation on the display. '
While the heating accelerator is in operation, the heating level can be increased at
any time. The "full power" time will be modified accordingly. If the power is reduced
by turning the knob anticlockwise, option "A" is automatically deactivated.

Power Function

The power function allows the user to operate each heating zone continuously at the

maximum power for a time of no more than 10 minutes. This function can be used,

for example, to bring a large amount of water to the boil in a hurry, or to turn up the

   heat

under

meat.

Turn the knob clockwise and set heating level 9, then use the knob to set the "P"
position and release it. "P" appears on the corresponding zone display.
After 10 minutes, the power is reduced automatically, the knob returns to the 9
setting and the "P" disappears.
However, the power function can be turned ott at any time by reducing the heating
level. .
When the power function is selected for one heating zone (e.g. the left front zone),
the power absorbed by the second zone (Ieft rear zone) might be reduced to supply
the maximum available energy to the first zone.
Consequently, the power function takes priority over the heating accelerator.
If a pan is removed from the cooking zone while the power function is on, the
function is switched off.

HOB

ATTENTION:

Metal items such as cutlery or lids must never be placed on the surface of the hob since they may become
hot.

Cooking zones

The appliance is equipped with 5 cooking zones having different diameters and

powers. Their positions are clearly marked by rings, while the heating power is only
