Products sold in GB only

: Your product is fitted

with an BS 1363/A approved electric plug with
internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets,
it should be cut off and an appropriate plug fit-
ted in its place by an authorised customer serv-
ice agent. The replacement plug should have the
same fuse rating as the original plug.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be in-
serted into a mains socket elsewhere.

Products sold in AUS and NZ only

: Use a resid-

ual current device (RCD) with a rated residual
current of 30 mA or less.

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.

Intended Use

The machine is intended for hammer drilling in
concrete, brick and stone, as well as for light
chiselling work. It is also suitable for drilling
without impact in wood, metal, ceramic and
plastic. Machines with electronic control and
right/left rotation are also suitable for screw-
driving.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.

1

SDS-plus tool holder

2

Dust protection cap

3

Locking sleeve

4

Lock ring of the tool holder

5

Mode selector switch

6

Vibration damper

7

On/Off switch

8

Rotational direction switch

9

Button for depth stop adjustment

10

Auxiliary handle

11

Depth stop

12

Quick change keyless chuck *

13

Front sleeve of the quick change keyless
chuck *

14

Retaining ring of the quick change keyless
chuck *

15

Extraction sleeve of the dust extraction at-
tachment *

16

Clamping screw for the dust extraction at-
tachment *

17

Depth stop of the dust extraction attach-
ment *

18

Telescopic pipe of the dust extraction at-
tachment *

19

Wing bolt of the dust extraction attachment *

20

Guide pipe of the dust extraction attach-
ment *

* Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
