The knurled surface of the depth stop

17

 must face down-

ward.

– Insert the SDS-plus drilling tool to the stop into the SDS-

plus tool holder

3

. Otherwise, the movability of the SDS-

plus drilling tool can lead to incorrect adjustment of the
drilling depth.

– Pull out the depth stop until the distance between the tip of

the drill bit and the tip of the depth stop corresponds with
the desired drilling depth

X

.

Changing the Chiselling Position (Vario-Lock)

The chisel can be locked in 36 positions. In this manner, the
optimum working position can be set for each application.

– Insert the chisel into the tool holder.
– Turn the mode selector switch

13

 to the “Vario-Lock” posi-

tion (see “Setting the operating mode”, page 19).

– Turn the tool holder to the desired chiselling position.
– Turn the mode selector switch

13

 to the “chiselling” posi-

tion. The tool holder is now locked.

– For chiselling, set the rotation direction to right rotation.

Inserting Screwdriver Bits (see figure N)



Apply the power tool to the screw/nut only when it is
switched off.

Rotating tool inserts can slip off.

To work with screwdriver bits, a universal bit holder

31

 with

SDS-plus shank (accessory) is required.

– Clean the shank end of the adapter shank and apply a light

coat of grease.

– Insert the universal bit holder with a turning motion into

the tool holder until it automatically locks.

– Check the locking effect by pulling the universal bit holder.
– Insert a screwdriver bit into the universal bit holder. Use

only screwdriver bits that match the screw head.

– To remove the universal bit holder, pull the locking sleeve

5

 toward the rear and remove the universal bit holder

31

out of the tool holder.

Vibration Damper

The integrated vibration damper reduces occurring vibra-
tions.

The soft grip handle increases the safety against slipping off
and thus provides for a better grip and handling of the power
tool.

Recommendations for Optimal Handling of the Battery

Protect the battery against moisture and water.

Store the battery only within a temperature range between
– 20 ° C and 50 ° C. As an example, do not leave the battery in
the car in summer.

Occasionally clean the venting slots of the battery using a soft,
clean and dry brush.

A significantly reduced working period after charging indi-
cates that the battery is used and must be replaced.

Observe the notes for disposal.

Maintenance and Service

Maintenance and Cleaning



Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.



For safe and proper working, always keep the machine
and ventilation slots clean.



A damaged dust protection cap should be changed im-
mediately. We recommend having this carried out by
an after-sales service.

– Clean the tool holder

3

 each time after using.

After-sales Service and Application Service

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:

www.bosch-pt.com

Bosch’s application service team will gladly answer questions
concerning our products and their accessories.

In all correspondence and spare parts orders, please always
include the 10-digit article number given on the nameplate of
the product.
