 27

en

Care and daily cleaning

4.

Fit the threaded ring onto the housing

and screw tight in the clockwise

direction without using force.

5.

Place the outlet funnel onto the filter

holder until it audibly clicks into place.

6.

Screw pulp nozzle into the filter holder.

The fruit press attachment is now prepared.

Use

W

Warning

Risk of injury!

Do not reach into the feed chute with your

hands.

Caution!

– Remove hard fruit peel, pips and stalks.

– Berries such as e.g. currants can be

pressed together with their stalks.

– Fruit with larger pips and stones such as

e.g. plums and cherries must have their

pips or stones removed before juicing.

– Do not process frozen fruit.

– Do not apply great force with the pusher.

X

Fig.

N

1.

Fit the prepared attachment onto the

drive of the base unit, holding it at an

angle.

2.

Turn the attachment anticlockwise until

you hear it click into position. Tighten

threaded ring.

3.

Fit the filling tray and insert the pusher

in the feed chute.

4.

Prepare the fruit. Chop up large fruit

beforehand so it fits into the feed

chute without having to be pressed in.

Remove larger pips and stones (e.g.

cherries, plums).

■

Place one container under each of the

apertures for juice and for the pulp.

■

Add the prepared fruit to the filling tray.

5.

Connect the mains plug. Switch on the

appliance.

6.

Use the pusher to slide the fruit down

the feed chute, applying light pressure.

7.

The pressed juice flows out from

the outlet funnel. The pulp (solid

components) is pressed through the

pulp nozzle.

8.

Adjust the pulp nozzle. Unscrewing

makes the pulp more moist; screwing

in makes it dryer and more juice flows

from the funnel. If the pulp is too dry,

unscrew the nozzle, to avoid clogging

the appliance with the pulp.

9.

Once you have finished, switch off the

appliance and pull out the mains plug.

10.

Remove the filling tray and pusher.

11.

Hold down the release button and

turn the attachment clockwise until it

disengages.

■

Remove the attachment, take it apart

and clean all parts.

X

 “Care and daily

cleaning” see page 27

12.

To remove the filter insert, insert the

hook into the hole in the filter insert and

carefully extract.

Caution!

Pay special attention to the juice squeezing

process. Make sure filter openings are not

clogged. Clogging of the housing outlet

with the pulp of juicy fruits can cause the

flooding of the drive unit.

If the housing outlet becomes clogged,

switch off the appliance and pull out the

mains plug. Remove the attachment, take it

apart and clean all parts.

X

 “Care and daily

cleaning” see page 27

Care and daily cleaning

The appliance, all attachments and the

relevant accessories must be thoroughly

cleaned after each use.

W

Risk of electric shock!

– Disconnect the mains cable from the

socket prior to cleaning.

– Never immerse the base unit in liquids

and do not clean in the dishwasher.

W

Risk of injury!

Do not reach into the sharp blades and

edges of the shredding and slicing inserts.

Clean them with a brush.
