26

en

Fruit press attachment

3.

Insert worm gear into the housing.

4.

Insert grinding ring into the housing.

Note shape of the parts!

5.

Insert grinding cone with the square

shaft into the corresponding opening of

the worm gear.

6.

Place grinding chamber on the housing.

Recess on the grinding chamber must

be situated on the lug on the housing.

7.

Fit the threaded ring onto the housing

and screw tight in the clockwise

direction without using force.

Use

W

Risk of injury!

■

Do not reach into the feed chute with

your hands.

■

Do not look into the feed chute during

operation, as the bouncing particles can

hurt your eye.

Caution!

When the mill is attached, never use reverse

function. Attachment may be damaged!

X

Fig.

L

1.

Fit the prepared attachment onto the

drive of the base unit, holding it at an

angle.

2.

Turn the attachment anticlockwise until

you hear it click into position. Tighten

threaded ring.

3.

Fit the filling tray.

4.

Place a suitable container under the

attachment. Fill the filling tray.

X

 “Tips”

see page 28

Caution!

Never allow the grain mill attachment to run

without ingredients.

5.

Set the degree of grinding by turning the

setting ring:

– anticlockwise = coarser grain

– clockwise = finer grain

Always select a value between:

– STOP = coarsest degree of grinding

– 1 = finest degree of grinding (never

use it at the beginning)

STOP

1

6.

Connect the mains plug. Switch on the

appliance.

Caution!

The appliance may be operated

continuously for a maximum of 15 minutes.

Then leave the appliance to cool down for

45 minutes!

7.

The flour trickles through the discharge

chute.

8.

Degree of grinding can be re-adjusted in

small steps during operation.

Caution!

Setting it beyond the STOP line during

operation can damage the appliance.

9.

Once you have finished, switch off the

appliance and pull out the mains plug.

10.

Remove the filling tray.

11.

Hold down the release button and

turn the attachment clockwise until it

disengages.

12.

Remove the attachment, take it apart

and clean all parts.

X

 “Care and daily

cleaning” see page 27

Fruit press attachment

For squeezing juice out of fruits such as

e.g. raspberries, currants, strawberries,

gooseberries or grapes and tomatoes.

Preparation

Note:

 selection of the filter insert

determines the content of fruit pulp in the

juice. Do not press fruit whose pips are

similar in diameter to the hole diameter in

the filter insert (e.g. raspberries).

X

Fig.

M

■

Make sure that the sealing rings are

fitted onto the filter holder and the worm

gear. If not, insert them into the sealing

grooves of these parts.

1.

Insert the filter insert into the filter holder

and press it into place.

2.

Insert the worm gear into the housing.

3.

Insert the filter holder into the housing.

Lug on the filter holder must be situated

in the recess on the housing.
