24 

en

Care and daily cleaning 

X

Sequence of figures

J

1.

Hold the base unit by the carrying 

handle and carefully tip up so the 

drive points upwards. Possibly turn the 

base unit to make the buttons easily 

accessible.

2.

Insert the driving shaft with the spring 

element pointing down in the drive of the 

base unit.

Caution!

It should be possible to push the driving 

shaft down lightly with your finger. It must 

not get sticky with residue from juice or 

become blocked with pips or foreign bodies.

3.

Fit the collecting tray onto the drive at 

an angle.

4.

Turn the collecting tray anticlockwise 

until you hear it click into position.

5.

Fit the filter insert onto the collecting 

tray.

6.

Fit the pressing cone onto the driving 

shaft.

The citrus press attachment is now fitted to 

the base unit and prepared.

Use

X

Sequence of figures

K

1.

Cut the citrus fruits in half.

2.

Place a suitable container under the 

attachment.

3.

Connect the mains plug. Switch on the 

appliance. The drive is running.

Caution! (MFW36.../MFW38...)

After switching on, the appliance runs at 

speed 

2

 (fast). To use the citrus press, you 

must press button 

+

 once to switch 

to speed 

1

 (slow). 

X

 “Speed setting” see

page 20

4.

Position the halved citrus fruits with 

the cut surface on the pressing cone 

and press down. As soon as the fruit 

is pressed onto the pressing cone, the 

cone will rotate.

5.

To finish the process, reduce the 

pressure on the cone.

6.

Once you have finished, switch off the 

appliance and pull out the mains plug.

7.

Hold down the release button and 

turn the attachment clockwise until it 

disengages.

8.

Remove the attachment, take it apart 

and clean all parts. 

X

 “Care and daily

cleaning” see page 24

Notes:

–

To obtain the largest amount of juice, 

the pressing procedure should be 

repeated a few times.

–

The filter insert with the pulp and pips 

should be emptied as necessary.

Care and daily cleaning

The appliance, all attachments and the 

relevant accessories must be thoroughly 

cleaned after each use.

W

Risk of electric shock!

–

Disconnect the mains cable from the 

socket prior to cleaning.

–

Never immerse the base unit in liquids 

and do not clean in the dishwasher.

W

Risk of injury!

Do not reach into the sharp blades and 

edges of the shredding and slicing inserts.

Caution!

–

Do not use any cleaning agents 

containing alcohol or spirits.

–

Do not use any sharp, pointed or metal 

objects.

–

Do not use abrasive cloths or cleaning 

agents.

Fig.

L

 gives an overview of how to clean 

the individual parts.

■ Wipe the outside of the base unit with a 

soft, damp cloth and dry off.

■ Dismantle the attachments used in 

reverse order (see „Preparation“ for the 

relevant attachment).

■ Clean all accessories with a detergent 

solution and a soft cloth/sponge or with 

a soft brush.

■ Allow all parts to dry.
