Overview

Overview

X

 Fig.

A

1  Base unit

a

Drive for attachments

b

Button 

ä

or 

k

*

c

Button 

ö

or 

+

*

d

Operation indicator

e

Release button

f

Carrying handle

g

Storage compartment with cover

h

Mains cable

i

Cable storage compartment

2  Base attachment

a

Housing

b

Feed chute

c

Filling tray

d

Pusher

e

Worm gear with agitator paddle

f

Threaded ring

3  Meat mincer insert

a

Blade

b

Perforated disc, fine*

c

Perforated disc, medium

d

Perforated disc, coarse

4

Sausage filler insert

a

Bearing ring

b

Sausage filler nozzle

5  Kebbe insert

a

Conical ring

b

Kebbe nozzle

X

 Fig.

B

6  Shredding attachment*

a

Housing

b

Feed chute

c

Cap

d

Filling tray

e

Pusher

f

Slicing insert

g

Shredding insert, coarse

h

Shredding insert, fine

i

Grating insert

7  Citrus press attachment*

a

Collecting tray

b

Filter insert

c

Pressing cone

d

Driving shaft with spring

* depending on the model

The operating instructions refer to different 

models of the appliance. An overview is 

provided on the pages that feature the 

figures. 

X

 Fig.

M

Spare parts and accessories are 

available from Customer Service or at 

www.bosch-home.com

. 

X

 “Spare parts

and accessories” see page 27

Before using for the first

time

Before the new appliance can be used, 

it must be fully unpacked, cleaned and 

checked.

Caution!

Never operate a damaged appliance!

■ Remove the base unit and all 

accessories from the packaging.

■ Remove the packaging material that is 

present.

■ Dismantle any assembled parts into 

their individual parts. Do this in reverse 

order, as described under „Preparation“.

■ Check all parts for completeness. 

X

 Fig.

A

 / 

B

■ Inspect all parts for visible damage.

■ Thoroughly clean and dry all parts 

before using for the first time.  

X

 “Care and daily cleaning” see

page 24
