Appendix
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
Figure 1
Step 2:
Save changes and exit BIOS Setup.
5-1-2 Configuring GIGABYTE SATA2/JMicron JMB362 SATA Controller
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available
SATA port on the motherboard. See the table below for the SATA controllers and their corresponding SATA
ports. Then connect the power connector from your power supply to the hard drive.
B. Configuring SATA controller mode in BIOS Setup
Make sure to configure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST. In BIOS Setup, go to
Inte-
grated Peripherals
. To enable RAID, see the table below for configuring different SATA Controllers for RAID.
Controller Connectors
BIOS Settings
GIGABYTE GSATA2_6/7
Set
Onboard GSATA/IDE Ctrl
to
Enabled
SATA2
Set
Onboard GSATA/IDE Mode
to
RAID/IDE
JMicron
eSATA ports
Set
Onboard ESATA controller
to
Enabled
JMB362
Set
Onboard ESATA Mode
to
RAID
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
OnChip SATA Controller
[Enabled]
OnChip SATA Type
[Native IDE]
x OnChip SATA Port4/5 Type
IDE
x OnChip SATA RAID5 Support
Enabled
OnChip SATA3.0 Suuport
[Enabled]
Onboard GSATA/IDE Ctrl
[Enabled]
Onboard GSATA/IDE Mode
[RAID/IDE]
Onboard ESATA controller
[Enabled]
Onboard ESATA Mode
[RAID]
Onboard LAN Function
[Enabled]
Onboard LAN Boot ROM
[Disabled]
SMART LAN
[Press Enter]
Onboard Audio Function
[Enabled]
Onboard 1394 Function
[Enabled]
Onboard USB 3.0 Controller
[Enabled]
USB Controllers
[Enabled]
USB Legacy Function
[Enabled]
USB Storage Function
[Enabled]
Onboard Serial Port 1
[3F8/IRQ4]
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
