- 73 -

Unique Features

4-7  Auto Green

Auto  Green  is  an  easy-to-use  tool  that  provides  users  with  simple  options  to  enable  system  power  savings

via a Bluetooth cell phone.  When the phone is out of the range of the computer's Bluetooth receiver, the sys-

tem will enter the specified power saving mode.

Selecting a system energy saving mode:

Depending on your needs, select a system power saving mode on the Auto Green
main menu and click

Save

 to save the settings.

  Button

Description

  Standby

Enters Power on Suspend mode

  Suspend

Enters Suspend to RAM mode

  Disable

Disables this function

The Configuration dialog box:

First, you have to set your Bluetooth cell phone as a portable key. On the Auto Green

main  menu,  click

Configure

  and  then  click

Configure  BT  devices

.  Select  the  Blu-

etooth cell phone that you want to use as the portable key

(Note 1)

. (If the screen doesn't

display your Bluetooth cell phone, click

Refresh

 to let Auto Green re-detect the device.)

Before creating a Bluetooth cell phone key, make sure your motherboard
has a Bluetooth receiver and you have turned on the search and Bluetooth
functions on your phone.

Configuring other Bluetooth settings:

On the

Other Settings

 tab, you can set how much time it takes to scan your Bluetooth

cell  phone  key,  how  many  times  to  rescan  the  key  to  make  sure  it  is  in  range  of  your
computer,  and  when  to  turn  off  the  hard  drive  if  the  system  energy  saving  state  lasts
over  the  predetermined  period  of  time. After  completing  the  settings,  click

Set

  for  the

settings to take effect and then click

Exit

 to quit.

Configuring the Bluetooth cell phone key:

After you select a cell phone, the

Add Bluetooth Device Wizard

 as shown on the left

will appear. Enter a passkey (8~16 digits recommended) which will be used for pairing
with the cell phone. Then enter the same passkey on your cell phone.

•  Device Scan Time (sec.):

Set the length of time Auto Green scans your Bluetooth cell phone key, ranging from 5 to 30 seconds in 5-second increment.

Auto Green searches for the key based on the length of time you set.

•  Rescan Times:

Set how many times Auto Green will rescan your Bluetooth cell phone key if it does not detect it, ranging from 2 to 5 times. Auto

Green will keep rescanning according to the times you set. When the times limit is reached and your Bluetooth cell phone key

is still not detected, the system will enter the selected energy saving mode.

•  Turn off HD:

Set when to turn off the hard drive. If the system inactivity time exceeds the specified time limit, the hard drive will be turned off.

The Bluetooth dongle included in the motherboard package

(Note 2)

allows

you  to  wake  up  the  system  from  Suspend  to  RAM  mode  without  the

need to press the power button first.

(Note 1)  If your cell phone has been configured as the Auto Green key, you'll not be able to use it to connect to other

Bluetooth device(s) when Auto Green is enabled.

(Note 2)  Whether the Bluetooth dongle is included depends on the motherboard models. Before installing the Bluetooth

dongle, be sure to turn off other Bluetooth receiver on your computer.
