BIOS Setup
- 46 -
OnChip SATA Port4/5 Type (AMD SB850 South Bridge, SATA3_4~SATA3_5 connectors)
This option is configurable only when
OnChip SATA Type
is set to
RAID
or
AHCI
. Configures the oper-
ating mode of the integrated SATA3_4/SATA3_5 connectors.
IDE
Disables RAID for the SATA controller and configures the SATA controller to PATA
mode. (Default)
As SATA Type The mode depends on the
OnChip SATA Type
settings.
OnChip SATA RAID5 Support (AMD SB850 South Bridge, SATA3_0~SATA3_5 connectors)
Enables or disables RAID 5 support for the SATA controller integrated in the AMD SB850 South Bridge.
This option is configurable only when
OnChip SATA Type
is set to
RAID
.
OnChip SATA3.0 Support
Enables or disables the SATA 6Gb/s function integrated in the Chipset. When set to
Disabled
, the SATA
controller will operate in SATA 3Gb/s mode. (Default: Enabled)
Onboard GSATA/IDE Ctrl (GIGABYTE SATA2 Chip, GSATA2_6/7 Connectors)
Enables or disables the SATA controller integrated in the GIGABYTE SATA2 chip. (Default: Enabled)
Onboard GSATA/IDE Mode (GIGABYTE SATA2 Chip, GSATA2_6/7 Connectors)
Allows you to decide whether to configure the SATA controller integrated in the GIGABYTE SATA2 chip
to AHCI mode.
IDE
Configures the SATA controller to IDE mode. (Default)
AHCI
Configures the SATA controller to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specification that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
RAID/IDE
Enables RAID for the SATA controller; the IDE controller still operates in IDE mode.
Onboard ESATA controller (JMicron JMB362 Chip, eSATA Connectors on the Back Panel)
Enables or disables the SATA controller integrated in the JMicron JMB362 chip. (Default: Enabled)
Onboard ESATA Mode (JMicron JMB362 Chip, eSATA Connectors on the Back Panel)
Enables or disables RAID for the SATA controller integrated in the JMicron JMB362 chip or configures
the SATA controller to AHCI mode.
IDE
Disables RAID for the SATA controller and configures the SATA controller to IDE
mode. (Default)
AHCI
Configures the SATA controller to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specification that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
RAID
Enables RAID for the SATA controller.
Onboard LAN Function
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to
Disabled
.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
