In the following procedure, we'll create RAID 0 as an example.
1.  Under the

RAID Mode

section, press the <SPACE> key to select

RAID 0

.

2.  Set the

Stripe Block

 size. 64 KB  is the default.

3.  Under the

Drives Assignments

 section, press the up or down arrow key to highlight a drive.

4.  Press the <SPACE> key or <Y>to change the

Assignment

 option to

Y

. This action adds the drive to the

disk array. The

Drv

 section will show the number of disks assigned.

5.  Press <Ctrl>+<Y> keys  to save  the information. The message  in Figure 6 will appear. Press <Ctrl+Y> to

input the array name. If you do not input the array name, the default array name will be used.

Figure 7

Fast Initialization option has been selected

It will erase the MBR data of the disks.

<Press Ctrl-Y key if you are sure to erase it>

<Press any other key to ignore this option>

Press Ctrl-Y to Modify Array Capacity or press any

other key to use maximum capacity...

Figure 8

7.  Then,  the  message  in  Figure  8  will  appear.  Press  <Ctrl>+<Y>  to  set  the  capacity  of  the  RAID  array  or

press other keys to set the array to its maximum capacity.

Figure 6

Please press Ctrl-Y key to input the LD name

or press any key to exit.

If you do not input any LD name, the default

LD name will be used.

6.  When the next message appears, press <Ctrl>+<Y> to clear the MBR or press other keys to ignore this

option.

8. After  the  creation  is  complete,  the  screen  will  return  to

LD  View  Menu

  where  you  will  see  the  newly-

created array.

9. Press <Esc> to return to

Main Menu

 and press <Esc> again if you want to exit the RAID BIOS utility.
