BIOS Setup
2-3 MB Intelligent Tweaker(M.I.T.)
•
Whether the system will work stably with the overclock/overvoltage settings you made is depen-
dent on your overall system configurations. Incorrectly doing overclock/overvoltage may result in
damage to CPU, chipset, or memory and reduce the useful life of these components. This page is
for advanced users only and we recommend you not to alter the default settings to prevent system
instability or other unexpected results. (Inadequately altering the settings may result in system's
failure to boot. If this occurs, clear the CMOS values and reset the board to default values.)
•
When the
System Voltage Optimized
item blinks in red, it is recommended that you set the
System Voltage Control
item to
Auto
to optimize the system voltage settings.
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
MB Intelligent Tweaker(M.I.T.)
CPU Clock Ratio
[Auto]
2800Mhz
CPU NorthBridge Freq.
[Auto]
2000Mhz
CPU Host Clock Control
[Auto]
x CPU Frequency(MHz)
200
PCIE Clock(MHz)
[Auto]
PCIe Spread Spectrum
[Disabled]
HT Link Frequency
[Auto]
Set Memory Clock
[Auto]
x Memory Clock
x6.66
1333Mhz
DRAM Configuration
[Press Enter]
******** System Voltage Optimized ********
System Voltage Control
[Auto]
x DRAM Voltage Control
Auto
x NB Voltage Control
Auto
x NB PCIE Voltage Control
Auto
x CPU NB VID Control
Auto
x CPU Voltage Control
Auto
Normal CPU Vcore
1.3250V
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
CPU Clock Ratio
Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the CPU
being used.
CPU NorthBridge Freq.
Allows you to alter the North Bridge controller frequency for the installed CPU. The adjustable range is
dependent on the CPU being used.
CPU Host Clock Control
Enables or disables the control of CPU host clock.
Auto
(default) allows the BIOS to automatically adjust
the CPU host frequency.
Manual
allows the
CPU Frequency (MHz)
item below to be configurable.
Note: If your system fails to boot after overclocking, please wait for 20 seconds to allow for automated
system reboot, or clear the CMOS values to reset the board to default values.
CPU Frequency(MHz)
Allows you to manually set the CPU host frequency. The adjustable range is from 200 MHz to 500 MHz.
This option is configurable only when
CPU Host Clock Control
is set to
Manual
.
Important
It is highly recommended that the CPU frequency be set in accordance with the CPU specifi
-
cations.
PCIE Clock(MHz)
Allows you to manually set the PCIe clock frequency. The adjustable range is from 100 MHz to 150 MHz.
Auto
sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)
