Chapter 1: Introduction

1�3

Specifications

Specifications

CPU Support

Support for 12th Generation Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Pentium® processors/

Intel® Celeron® processors in the LGA1700 package

* Please refer to www.biostar.com.tw for CPU support list.

Chipset

Intel® B660

Memory

Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2800/ 2933/ 3200/ 3600(OC)/ 3733(OC)/ 3800(OC)/

3866(OC)/ 4600+(OC)

4x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB Memory

Each DIMM supports non-ECC 4/8/16/32GB DDR4 module

Support Intel® Extreme Memory Profile (XMP) memory modules

* Please refer to www.biostar.com.tw for Memory support list.

Storage

-- Total supports 2x M.2 socket and 4x SATA III (6Gb/s) ports

4x SATA III Connector (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology

1x M.2 (M Key) Socket (M2_PCIEG4_64G):

Supports M.2 Type 2280 SSD module

Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD

1x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA):

Supports M.2 Type 2242/2260/2280 SSD module

Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD

Supports M.2 Type SATA module

LAN

Intel® I219V
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

Audio Codec

ALC897

7.1 Channels, High Definition Audio, Hi-Fi(Front)

USB

6x USB 3.2 (Gen1) port (4 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)

Expansion Slots

1x PCIe 4.0 x16 Slot (x16 mode)

1x PCIe 3.0 x16 Slot (x4 mode)

1x PCIe 3.0 x1 Slot

Rear I/Os

B660MX-E PRO

2x WIFI Antenna Port

1x PS/2 Keyboard/ Mouse Port

1x HDMI

1x VGA+DVI Port

4x USB 3.2 (Gen1) port

2x USB 2.0 port

1x LAN port

3x Audio Jack

B660MH-E PRO

2x WIFI Antenna Port

1x PS/2 Keyboard/ Mouse Port

1x HDMI

1x VGA Port

4x USB 3.2 (Gen1) port

2x USB 2.0 port

1x LAN port

3x Audio Jack

Internal I/Os

4x SATA III Connector (6Gb/s)

1x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel® CNVi

2x USB 2.0 Header (each header supports 2 USB 2.0 ports)

1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)

1x 8-Pin Power Connector

1x 24-Pin Power Connector

1x CPU Fan Connector

1x CPU water cooling connector (CPU_OPT)

1x System Fan Connector

1x Front Panel Header

1x Front Audio Header

1x Internal Stereo Speaker Header

1x Clear CMOS Header

1x COM Port Header

1x TPM Header

2x LED Header (5V)

1x LED Header (12V)

* M.2 (E key) Wi-Fi card is not provided

Form Factor

uATX Form Factor, 244 mm x 244 mm

OS Support

Windows 10(64bit) / Windows 11(64bit)

* Biostar reserves the right to add or remove support for any OS with or without notice.
