99

Chapter 12

NAT Forwarding

Tips:

•  You can add multiple port triggering rules according to your network need.
•  The triggering ports can not be overlapped.
•  If the application you need is not listed in the Existing Applications list, please enter the parameters manually. You

should verify the external ports the application uses first and enter them into

External Port

 field according to the

format the page displays.

12  4   Make Applications Free from Port Restriction

by DMZ

When a PC is set to be a DMZ (Demilitarized Zone) host on the local network, it is totally
exposed to the internet, which can realize the unlimited bidirectional communication
between internal hosts and external hosts. The DMZ host becomes a virtual server with
all ports opened. When you are not clear about which ports to open in some special
applications, such as IP camera and database software, you can set the PC to be a DMZ
host.

Note:

When DMZ is enabled, the DMZ host is totally exposed to the internet, which may bring some potential safety hazards. If
DMZ is not in use, please disable it in time.

I want to:

Make the home PC join the internet online game without port restriction.

For example,

due to some port restriction, when playing the online games, you can log

in normally but cannot join a team with other players. To solve this problem, set your PC
as a DMZ host with all ports open.

How can I do that?

1

Assign a static IP address to your PC, for example 192.168.0.100.

1

Visit

http://tplinkwifi.net

 or

http://192.168.0.1

, and log in with your TP-Link ID or the

password you set for the router.

2

Go to

Advanced

 >

 NAT Forwarding

>

DMZ

 and tick to enable DMZ.

2

Enter the PC’s IP address 192.168.0.100 manually in the

DMZ Host IP Address

field.
