95

Chapter 12

NAT Forwarding

12  1   ALG

ALG allows customized Network Address Translation (NAT) traversal filters to be plugged
into the gateway to support address and port translation for certain application layer
“control/data” protocols such as FTP, TFTP, H323 etc. It is recommended to keep the
default settings.
You may need to disable SIP ALG when you are using voice and video applications to
create and accept a call through the router, since some voice and video communication
applications do not work well with SIP ALG.
Visit

http://tplinkwifi.net

 or

http://192.168.0.1

, and log in with your TP-Link ID or the

password you set for the router. Go to

Advanced

 >

Security

 >

ALG

.

12  2   Set Up Public Services on The Local Network by

Virtual Servers

Virtual Servers are used to set up public services on the local network. A virtual server
is defined as an external port, and all requests from the Internet to this external port
will be redirected to a designated computer, which must be configured with a static or
reserved IP address. When you build up a server on the local network and want to share
it on the Internet, Virtual Servers can realize the service and provide it to the Internet
users.
The table displays the relevant parameters of the virtual server.
To set up a Virtual Server rule:
1. Visit

http://tplinkwifi.net

 or

http://192.168.0.1

, and log in with your TP-Link ID or the

password you set for the router.

2. Go to

Advanced

>

NAT Forwarding

>

 Virtual Servers

and click

.

3. Select an interface name from the drop-down list.
