16

 | English

1 609 92A 15H | (16.1.15)

Bosch Power Tools

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.



Do not continue to press the On/Off switch after the
machine has been automatically switched off.

The bat-

tery can be damaged.

Observe the notes for disposal.

Removing the battery

The battery

3

 is equipped with two locking levels that should

prevent the battery from falling out when pushing the battery
unlocking button

4

 unintentionally. As long as the battery is

inserted in the power tool, it is held in position by means of a
spring.

To remove the battery

3

, press the battery unlocking button

4

and pull the battery toward the rear out of the power tool.

Do

not exert any force when doing this.

Battery Charge-control Indication (see figure A)

The three green LEDs of the battery charge-control indicator

18

 indicate the charge condition of the battery

3

. For safety

reasons, it is only possible to check the status of the charge
condition when the machine is at a standstill.

Press button

17

 to indicate the charge condition. This is also

possible when the battery

3

 is removed.

When no LED lights up after pushing button

17

, then the bat-

tery is defective and must be replaced.

Replacing/Inserting the Saw Blade



When mounting the saw blade, wear protective gloves.

Danger of injury when touching the saw blade.

Selecting a Saw Blade

An overview of recommended saw blades can be found at the
end of these instructions. Use only T-shank saw blades. The
saw blade should not be longer than required for the intended
cut.

Use a thin saw blade for narrow curve cuts.

Inserting the Saw Blade (see figure B)



Clean the shank of the saw blade before inserting it.

An

unclean shank cannot be fastened securely.

Insert the saw blade

10

 into the stroke rod

19

 until it latches.

The SDS lever

11

 automatically snaps to the rear and the saw

blade is locked. Do not manually press the lever

11

 toward

the rear, otherwise you could damage the machine.

While inserting the saw blade, pay attention that the back of
the saw blade is positioned in the groove of the guide roller

9

.



Check the tight seating of the saw blade.

A loose saw

blade can fall out and lead to injuries.

Ejecting the Saw Blade (see figure C)



When ejecting the saw blade, hold the machine in such
a manner that no persons or animals can be injured by
the ejected saw blade.

Turn the SDS lever

11

 all the way forward in the direction in-

dicated by the arrow. The saw blade is released and ejected.

Dust/Chip Extraction



Dusts from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dusts can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dusts, such as oak or beech dust, are considered
as carcinogenic, especially in connection with wood-treat-
ment additives (chromate, wood preservative). Materials
containing asbestos may only be worked by specialists.

– As far as possible, use a dust extraction system suitable

for the material.

– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.



Prevent dust accumulation at the workplace.

Dusts can

easily ignite.

Connecting the Dust Extraction (see figures D – E)

Insert the vacuum connection

20

 into the opening of base

plate

7

.

Place a vacuum hose

21

 (accessory) onto the vacuum connec-

tion

20

. Connect the vacuum hose

21

 with a vacuum cleaner

(accessory). An overview for the connection of various vacuum
cleaners can be found at the end of these instructions.

To enable optimum dust extraction, use the splinter guard

22

if possible.

The vacuum cleaner must be suitable for the material being
worked.

When vacuuming dry dust that is especially detrimental to
health or carcinogenic, use a special vacuum cleaner.

Splinter Guard (see figure F)

The splinter guard

22

 can prevent fraying of the surface while

sawing wood. The splinter guard can only be used with certain
saw blade types, and only at a cutting angle of 0 °. When saw-
ing with the splinter guard, the base plate

7

 may not be offset

to the rear for sawing close to edges.

Insert the splinter guard

22

 into base plate

7

 from the front.

Sliding Shoe (see figure G)

The plastic guide plate

6

 of base plate

7

 reduces sensitive sur-

faces from being scratched up. When cutting metal, use the
steel sliding shoe

23

.

To mount the steel sliding shoe

23

, slide it onto base plate

7

from the front.

LED

Capacity

Continuous lighting 3 x green



2/3

Continuous lighting 2 x green



1/3

Continuous lighting 1 x green



1/3

Flashing light 1 x green

Reserve
