 English |

15

Bosch Power Tools

1 609 92A 15H | (16.1.15)

Technical Data

Noise/Vibration Information

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signif-
icantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2009/125/EC (Regulation
1194/2012), 2011/65/EU, 2004/108/EC, 2006/42/EC
including their amendments and complies with the following
standards: EN 60745-1, EN 60745-2-11.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 08.01.2015

Assembly



Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.

Battery Charging



Use only the battery chargers listed on the accessories
page.

Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

Cordless Jigsaw

GST 18 V-LI S GST 18 V-LI B

Article number

3 601 EA5 1.. 3 601 EA6 1..

Rated voltage

V=

18

18

Stroke rate at
no load n

0

min

-1

550 – 2 700

0 – 2 700

Stroke

mm

23

23

Cutting capacity,
max.
– in wood
– in  aluminium
– in non-alloy steel

mm
mm
mm

120

20

8

120

20

8

Bevel cuts
(left/right), max.

°

–

45

Weight according to
EPTA-Procedure
01/2003

kg

2.2/2.4

1

2.2/2.4

1

Permitted ambient
temperature
– during  charging
– during operation

2

and during storage

° C

° C

0 ... + 45

– 20 ... + 50

0 ... + 45

– 20 ... + 50

Recommended
batteries

GBA 18 V..

GBA 18 V..

Recommended
chargers

AL 18..

GAL 3680

AL 18..

GAL 3680

1 depending on the battery pack being used

2 limited performance at temperatures < 0 ° C

GS

T 18 V-LI

 S

GS

T 18 V-LI

 B

Sound emission values determined
according to EN 60745-2-11.

Typically the A-weighted noise levels
of the product are
Sound pressure level
Sound power level
Uncertainty K

Wear hearing protection!

dB(A)
dB(A)

dB

79
90

3

81
92

3

Vibration total values a

h

 (triax vector

sum) and uncertainty K determined
according to EN 60745:
Cutting board:
a

h

K
Cutting sheet metal:
a

h

K

m/s

2

m/s

2

m/s

2

m/s

2

7.5
1.5

8

1.5

6

1.5

8.5
1.5

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
