ENGLISH (Original instructions)

Explanation of general view



1-1. Battery cartridge
1-2. Button
2-1. Lock-off button
2-2. Switch trigger
3-1. Indication lamp
4-1. Change lever
4-2. Protrusion on base frame
4-3. Base frame
5-1. Shear blades
5-2. Base frame
5-3. Blade cover
7-1. Groove
7-2. Base frame
8-1. Change lever
8-2. Protrusion on base frame
8-3. Base frame
9-1. Blade cover
10-1. Undercover
10-2. Locking lever
10-3. Press
10-4. Turn
11-1. Undercover
11-2. Shear blade
11-3. Crank

12-1. Blade cover
12-2. Shear blades
13-1. Recessed part of crank
13-2. Pins
13-3. Crank
13-4. Apply grease
14-1. Base plate
14-2. Hole in the base plate of shear

blades

14-3. Oval holes that are overlapped
16-1. Undercover
16-2. Locking lever
18-1. Groove in the undercover
18-2. Locking lever
22-1. Brush
23-1. Machine oil
24-1. Blade cover
25-1. Bent part of the base plate of shear

blades

26-1. Screws
27-1. Locking lever
27-2. Undercover
29-1. Groove in the undercover
29-2. Locking lever

30-1. Blade cover
31-1. Undercover
31-2. Locking lever
31-3. Press
31-4. Turn
32-1. Undercover
33-1. Screws
34-1. Crank
34-2. Shear blades
35-1. Grass shear blade cover
35-2. Grass shear blade
35-3. Storage case
38-1. Trimming direction
38-2. Tilt the blades
38-3. Hedge surface to be trimmed
39-1. String
43-1. Clamping nuts
43-2. Chip receiver
43-3. Screws on the shear blades
43-4. Blade cover to be always installed

before installing the chip receiver

44-1. Hook hole

SPECIFICATIONS

Model UM164D

Effective cutting width

160 mm

Stroke per minute (min

-1

) 1,250

Dimensions (L x W x H)

292 mm x 178 mm x 130 mm

Net weight

1.1 kg

Rated voltage

D.C. 10.8 V

• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003



END010-1

Symbols

The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.

  Take particular care and attention.



  Read instruction manual.



  Danger; be aware of thrown objects.



  Keep bystanders away.



  Cutting means continues to run after the

motor is switched off.

  Do not expose to moisture.




  Only for EU countries

Do not dispose of electric equipment or
battery pack together with household
waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment, 2006/66/EC on
batteries and accumulators and waste
batteries and accumulators and their
implementation in accordance with
national laws, electric equipment and
battery pack that have reached the end
of their life must be collected separately
and returned to an environmentally
compatible recycling facility.





Cd

Ni-MH

Li-ion
