5

de

en

Controls

Power on/off switch O / I

The power switch

O / I

(9) is used to switch

the appliance on or to switch it off fully

(power supply off).

Important:

 Before switching off, run the

cleaning programme or use the

e

off /

j

button (12) to switch off.

e

  off /

j

 button

When the

e

off /

j

 button (12) is pressed

briefly, the appliance rinses and switches

off� Pressing and holding down the

e

off /

j

button (12) displays the user settings or

starts the descaling and cleaning function.

h

 button

Press the

h

 button (11) to generate steam

for preparing milk froth�

start button

Press the

start

 button (10) to begin drink

preparation or to start a service programme�

Press the

start

 button (10) again during

drink preparation to cut the dispensing

process short�

“Coffee strength” rotary knob

This rotary knob (13) is used

to set the coffee strength�

h

to

g

Very mild

Mild

Mild +

Normal

Normal +

Strong

Overview

Figures A, B, C, D

and

 E

1

  Bean container

 2

  Aroma cover

3

  Selector for grind setting

 4

 Drawer

    (ground coffee/cleaning tablet)

5

  Brewing unit (

Fig. E

)

a)

 Brewing unit

b)

 Door

c)

 Eject lever for brewing unit

d)

 Lock

6

  Milk frother (

Fig. C

)

a)

 Steam valve

b)

 Metal  sleeve

c)

 Frothing tube

d)

 Steam  nozzle

e)

Air hole

7

  Coffee outlet, height-adjustable

8

  Drip tray (

Fig. D

)

a)

 Drip tray panel

b)

 Coffee grounds container

c)

 Drip tray for coffee outlet

d)

 Grate for coffee outlet

e)

 Float

9

  Power on/off switch

O / I

10

start

button

11

h

button

12

e

off

/

j

 button

13

  “Coffee strength” rotary knob

14

  “Drink selection” rotary knob

15

 Display

16

  Removable water tank

17

  Lid for water tank

 18

  Measuring spoon

    (insertion aid for water filter)

19

  Storage compartment for

    measuring spoon

20

  Power cable with storage compartment
