18 ENGLISH

OPERATION

Mowing

WARNING:

Before mowing, clear away sticks

and stones from mowing area. Furthermore, clear

away any weeds from mowing area in advance.

WARNING:

Always wear the safety goggles or

safety glasses with side shields when operating

the mower.

CAUTION:

If the cut grass or foreign object

blocks up inside of the mower body, be sure to

remove the lock key and battery cartridge and

wear gloves before removing the grass or foreign

object.

NOTICE:

Use this machine for mowing lawn only.

Do not mow weeds with this machine.

►

Fig.29

Firmly hold the handle with both hands when mowing.

The mowing speed guideline is approximately 7 to 14

meters per 10 seconds.

►

Fig.30

The center lines of the front wheels are guidelines to

mowing width. Using the center lines as guidelines,

mow in strips. Overlap by one half to one third the previ-

ous strip to mow the lawn evenly.

►

Fig.31:

1.

 Mowing width

2.

 Overlapping area

3.

 Center line

Change the mowing direction each time to prevent the

grass grain pattern from forming in just one direction.

►

Fig.32

Periodically check the grass basket for mowed grass.

Empty the grass before it becomes full. Before every

periodical check, be sure to stop the mower then

remove the lock key and the battery cartridge.

NOTICE:

Using the mower with the grass basket

full prevents smooth blade rotation and places

an extra load on the motor, which may cause

breakdown.

Mowing a long-grass lawn

Do not try to cut long grass all at once. Instead, mow

the lawn in steps. Leave a day or two between mowings

until the lawn becomes evenly short.

►

Fig.33

NOTE:

 Mowing long grass to a short length all at

once may cause the grass to die. The cut grass may

also block up inside of the mower body.

Emptying the grass basket

WARNING:

To reduce a risk of accident, reg

-

ularly check the grass basket for any damage or

weakened strength. Replace the grass basket if

necessary.

1.

  Release the switch lever and drive lever (for

DLM462/DLM532), or release the switch lever (for

DLM530).

2.

  Remove the lock key.

3.

  Open the rear cover and take out the grass basket

by holding the handle.

►

Fig.34:

1.

 Rear cover

2.

 Handle

3.

 Grass basket

4.

  Empty the grass basket.

MAINTENANCE

WARNING:

Always be sure that the lock

key and battery cartridge are removed from the

mower before storing or carrying the mower or

attempting to perform inspection or maintenance.

WARNING:

Always remove the lock key when

the mower is not in use. Store the lock key in a

safe place out of reach of children.

WARNING:

Wear gloves when performing

inspection or maintenance.

WARNING:

Always wear the safety goggles or

safety glasses with side shields when performing

inspection or maintenance.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

To maintain product SAFETY and RELIABILITY,

repairs, any other maintenance or adjustment should

be performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

Maintenance

1.

  Remove the lock key and battery cartridges, and

then close the battery cover.

2.

  Put the mower on its side so that the mowing

height adjusting lever comes to the upper side. Clean

grass clippings accumulated on the underside of mower

deck.

3.

  Pour water toward the bottom of the machine to

which the blade is attached.

NOTICE:

Do not wash the machine with high

pressure water.

4.

  Check all nuts, bolts, screws, etc. for tightness.

5.

  Inspect moving parts for damage, breakage, and

wear. Damaged or missing parts should be repaired or

replaced.

6.

  Store the mower in a safe place out of the reach of

children.

For DLM462/DLM532

NOTICE:

Do not pour water to the area shown in

the figure.

 Pouring water to the motor unit may cause

a malfunction of the machine.

►

Fig.35:

1.

 Area where water should not be poured
