EN - 11

–

to have been specifically trained

to use this type of equipment;

–

to have carefully read the safety

regulations and user instructions

contained in this manual;

–

you practise first on logs on the ground

or attached to trestles, in order to

get familiar with the machine and the

most suitable cutting techniques.

To use the machine proceed as follows:

•

Always disengage the chain brake, pulling the

lever towards you before using the throttle.

•

The machine must always be firmly held in

both hands,

with the left hand on the front

hand grip and the right hand on the rear hand

grip, even if the operator is left-handed.

  Stop the machine immediately

if the chain stops during sawing.

 NOTE

  During use, the battery is

protected against total drainage with a

protective device that switches off the

machine and stops it from working.

 6.5.1

Checks to be conducted

whilst working

6.5.1.a

Checking the chain tension

The chain tends to stretch gradually

as you work, so you need to check its

tension frequently (par. 6.1.3).

6.5.1.b

Checking the oil delivery

 IMPORTANT

   Never use the

machine without lubrication!

 Make sure the bar and the chain are

in place when you check the oil delivery.

Start the motor (par. 6.4) and check if the

chain oil is spread as shown in (fig. 18).

 6.6  FORESTRY WORK

 6.6.1  Delimbing a tree

 Make sure there is nothing or nobody

in the area where the branches will fall.

  For pruning high up using a rope

and a belt harness, carefully follow

the instructions under par. 6.7.

1.

Stand opposite the branch you want to cut.

2.

Start cutting lower branches

followed by the higher ones.

3.

Make first cut from the bottom towards the

top (Fig. 19.A). Complete delimbing by cutting

from top to bottom, as shown in (Fig. 19.B).

 6.6.2  Felling a tree

 IMPORTANT

   Where two or more persons

are working together on felling and bucking

operations, such operations must be performed

in separate areas at a distance from each

other of at least 2.5 times the height of the tree

being felled. Do not fell trees if this involves

risks of injuring people, coming into contact

with a power line or causing any form of

damage. If the tree should come into contact

with a main power line, report the incident

immediately to the network provider.

Before commencing the felling operations:

–

it is necessary to evaluate the natural

inclination of the tree, the part where the

branches are larger and the wind direction,

to assess how the tree will actually fall;

–

remove any dirt, stones, pieces of

bark, nails, metal staples and wire;

– clear the area around the tree and

find a stable place to stand;

– plan obstacle-free escape routes at a 45°

angle back and away from the direction of

the fall (Fig. 20) which allow the operator

to escape to a safe zone, about 2.5 times

the height of the tree being felled;

–

Stand uphill of the land onto which the tree

will probably roll or fall over after felling.

•

Performing a face notch

1.

Stand to the right of the tree,

behind the chainsaw.

2.

Saw a horizontal face notch to 1/3 of the

diameter of the tree, perpendicular to the

direction in which it will fall (Fig. 21.A).

•

 Felling back cut

1.

Perform the felling back cut at least

5 cm higher than the horizontal

face notch (Fig. 22.B).

2.

Perform the felling back cut leaving

sufficient wood to act as a "hinge”

(Fig.

22.C). The hinge wood will prevent the

tree from twisting and falling in the wrong

direction. Do not cut through the hinge.

3.

Reduce the thickness of this hinge without

pulling out the bar, until the tree falls.

4.

If there is any risk of the tree not falling

in the desired direction, or that it might

lose its balance moving backwards and

bending the toothed chain, stop cutting
