EN - 7

 IMPORTANT

  The example of the

Declaration of Conformity is provided

on the last pages of the manual.

 3.4  MAIN COMPONENTS

The machine is composed of a series

of main components that have the

following functions (fig.1):

A.  Motor

: supplies the drive power

to the cutting means.

B.  Front hand grip

: support hand grip

located on the front of the chainsaw. This

should be grasped using the left hand.

C.  Rear hand grip

: support hand grip located

on the rear of the chainsaw. This should be

grasped using the right hand. This hand

grip is fitted with the main throttle controls.

D.  Front hand guard

: protection device seated

between the front hand grip and the toothed

chain, to protect the hand against injuries

should it slip off the hand grip. This guard is

used as a device to trigger the chain brake.

E.  Fastening point:

 coupling device

used to fasten the chainsaw to a rope

or belt, and then hook it onto the

operator's harness using clasp clips.

F.  Guide bar

: supports and

guides the toothed chain.

G.  Toothed chain

: cutting element,

consisting of drive links fitted with

small blades called "teeth" and side

connections held in place by rivets.

H.  Chain restraint pin

: safety  device that

prevents uncontrolled movements of the

toothed chain should it break or slacken.

I.

Spiked bumper

: device installed

opposite the guide bar assembly

point acting as a pivot when it comes

into contact with a tree or trunk.

J.  Spiked bumper guard

: spiked

bumper cover to be fitted during

handling, transportation or storage

of the machine. This guard must be

removed when using the machine.

K.

Bar cover guard

: chainsaw cover on the

guide bar to be fitted during handling,

transportation or storage of the machine.

L.

Battery

: device that supplies electric current

to the tool; its specifications and regulations

for use are described in a specific manual.

M.

Battery charger

(accessory available

upon request, par. 15.2): device

used to recharge the battery.

4.  ASSEMBLY

  The safety regulations to follow

are described in chap. 2. Strictly

comply with these instructions to

avoid serious risks or dangers.

For storage and transport purposes, some

components of the machine may not be installed

in the factory and have to be assembled after

unpacking. Follow the instructions below.

 Unpacking and completing the assembly

should be done on a flat and stable surface,

with enough space for machine handling

and its packaging, always making use of

suitable equipment. Do not use the machine

until all the instructions provided in the

“ASSEMBLY” section have been carried out.

 4.1  ASSEMBLY COMPONENTS

The packaging holds the components needed

for assembly as listed in the table below:

Guide bar fitted with bar cover

Toothed chain

Key

Documentation

 4.1.1

Unpacking

1.

Carefully open the packaging, paying

attention not to lose components.

2.

Consult the documentation in the

box, including these instructions.

3.

Remove all the unassembled

parts from the box.

4.

Remove the machine from the box.

5.

Dispose of the box and packaging in

compliance with local regulations.

 4.2  ASSEMBLY OF THE GUIDE

BAR AND TOOTHED CHAIN

 Always wear heavy duty gloves when

handling the bar and chain. Mount the

bar and chain very carefully so as not to

impair the safety and efficiency of the

machine. If in doubt, contact your dealer.

  Perform all operations after

removing the battery.

  Before assembling the bar, check that

the chain brake is not engaged (par. 5.4).
