15 ENGLISH

The saw chain may become loose after many hours

of use. From time to time check the saw chain tension

before use.

1.

Release the chain brake by pulling the front hand

guard.

2.

Loosen the retaining nut a bit to loosen the

sprocket cover lightly.

►

Fig.15:

1.

 Retaining nut

3.

  Lift up the guide bar tip slightly and adjust the

chain tension. Turn the chain adjusting screw clockwise

to tighten, turn it counterclockwise to loosen.

For chain blade 90PX and 91PX:

Tighten the saw chain until the lower side of the saw

chain fits in the guide bar rail as illustrated.

►

Fig.16:

1.

 Guide bar

2.

 Saw chain

3.

 Chain adjust

-

ing screw

For chain blade 25AP:

Tighten the saw chain so that the gap between the cen-

ter of the lower side of the guide bar and the saw chain

becomes approximately 1 mm to 2 mm.

4.

Keep holding the guide bar lightly and tighten the

sprocket cover.

For chain blade 90PX and 91PX:

Make sure that the saw chain does not loose at the

lower side.

For chain blade 25AP:

Make sure that the gap between the center of the lower

side of the guide bar and the saw chain is approximately

1 mm to 2 mm.

5.

Tighten the retaining nut to secure the sprocket

cover.

►

Fig.17:

1.

 Retaining nut

OPERATION

Lubrication

Saw chain is automatically lubricated when the tool is in

operation. Check the amount of remaining oil in the oil

tank periodically through the oil inspection window.

To refill the tank, lay the chain saw on its side, then

push the oil tank cap, and then remove the oil tank

cap. The proper amount of oil is 200 ml. After refilling

the tank, make sure that the oil tank cap is tightened

securely.

►

Fig.18:

1.

 Oil tank cap

2.

 Oil inspection window

After refilling, hold the chain saw away from the

tree. Start it and wait until lubrication on saw chain is

adequate.

►

Fig.19

NOTICE:

When filling the chain oil for the first

time, or refilling the tank after it has been com

-

pletely emptied, add oil up to the bottom edge of

the filler neck. The oil delivery may otherwise be

impaired.

NOTICE:

Use the saw chain oil exclusively for

Makita chain saws or equivalent oil available in

the market.

NOTICE:

Never use oil including dust and parti-

cles or volatile oil.

NOTICE:

When pruning trees, use botanical oil.

Mineral oil may harm trees.

NOTICE:

Before the cutting operation, make sure

that the provided oil tank cap is screwed in place.

WORKING WITH THE CHAIN SAW

CAUTION:

Keep all parts of the body away

from the saw chain when the motor is operating.

CAUTION:

Hold the chain saw firmly with

both hands when the motor is running.

CAUTION:

Do not overreach. Keep proper

footing and balance at all times.

NOTICE:

Never toss or drop the tool.

NOTICE:

Do not cover the vents of the tool.

Pruning trees

Bring the chain saw body into contact with the branch to

be cut before switching on. Otherwise it may cause the

guide bar to wobble, resulting in injury to operator. Saw

the wood to be cut by just moving it down by using the

weight of the chain saw.

►

Fig.20

If you cannot cut the timber right through with a single

stroke:

Apply light pressure to the handle and continue sawing

and draw the chain saw back a little.

►

Fig.21

When cutting thick branches, first make a shallow

undercut and then make the finish cut from the top.

►

Fig.22

If you try to cut off thick branches from the bottom, the

branch may close in and pinch the saw chain in the cut.

If you try to cut off thick branches from the top without a

shallow undercut, the branch may splinter.

►

Fig.23

Carrying tool

Before carrying the tool, always apply the chain brake

and remove the battery cartridges from the tool. Then

attach the guide bar cover. Also cover the battery car-

tridge with the battery cover.

►

Fig.24:

1.

 Guide bar cover

2.

 Battery cover
