13 ENGLISH

Indicator lamps

Remaining

capacity

Lighted

Off

Blinking

The battery

may have

malfunctioned.

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Tool / battery protection system

The tool is equipped with a tool/battery protection sys-

tem. This system automatically cuts off power to the

motor to extend tool and battery life. The tool will auto-

matically stop during operation if the tool or battery is

placed under one of the following conditions:

Overload protection

When the battery is operated in a manner that causes it to

draw an abnormally high current, the tool automatically stops

and the main power lamp blinks in green. In this situation, turn

the tool off and stop the application that caused the tool to

become overloaded. Then turn the tool on to restart.

Overheat protection

When the tool or battery is overheated, the tool stops automati-

cally and the main power lamp lights up in red. In this case, let the

tool and battery cool before turning the tool on again.

NOTE:

 In high temperature environment, the over-

heat protection likely to work and the tool stops

automatically.

Overdischarge protection

When the battery capacity is not enough, the tool stops auto-

matically and the main power lamp blinks in red. In this case,

remove the battery from the tool and charge the battery.

Main power switch

WARNING:

Always turn off the main power

switch when not in use.

To turn on the tool, press the main power switch until

the main power lamp lights up in green. To turn off,

press the main power switch again.

►

Fig.6:

1.

 Main power lamp

2.

 Mode indicator

3.

 Main power switch

NOTE:

 The main power lamp blinks in green if the

switch trigger is pulled under unoperatable conditions.

The lamp blinks in one of the following conditions.

•

When you turn on the main power switch while hold-

ing down the lock-off lever and the switch trigger.

•

When you pull the switch trigger while the chain

brake is applied.

•

When you release the chain brake while holding

down the lock-off lever and pulling the switch trigger.

NOTE:

 This tool employs the auto power-off function.

To avoid unintentional start up, the main power switch

will automatically shut down when the switch trigger

is not pulled for a certain period after the main power

switch is turned on.

You can use the tool in the Torque Boost mode for

cutting thick branches or hard branches. To use the tool

in the Torque Boost mode, when the tool is turned off,

press the main power switch for a few seconds until the

mode indicator lights up in green.

NOTE:

 You can use the tool in the Torque Boost

mode up to 60 seconds. Depending on the usage

conditions, this mode shifts to the normal mode in

less than 60 seconds.

NOTE:

 If the mode indicator blinks in green when

you press the main power switch for a few seconds,

the Torque Boost mode is not available. In this case,

follow the steps below.

•

The Torque Boost mode is not available right

after the cutting operation. Wait for more than 10

seconds, and then press the main power switch

for a few seconds again.

•

If you use the Torque Boost mode several times,

the use of the Torque Boost mode is restricted to

protect the battery. If the Torque Boost mode is

not available after waiting for more than 10 sec-

onds, replace the battery cartridge with a fully

charged one, or recharge the battery cartridge.

NOTE:

 If the main power lamp lights up in red or

blinks in red or green, refer to the instructions for tool/

battery protection system.

Switch action

WARNING:

For your safety, this tool is

equipped with lock-off lever which prevents the

tool from unintended starting. NEVER use the tool

if it runs when you simply pull the switch trigger

without pressing the lock-off lever. Return the

tool to our authorized service center for proper

repairs BEFORE further usage.

WARNING:

NEVER tape down or defeat pur-

pose and function of lock-off lever.

CAUTION:

Before installing the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

NOTICE:

Do not pull the switch trigger hard with-

out pressing the lock-off lever. This can cause

switch breakage.

To prevent the switch trigger from being accidentally

pulled, a lock-off lever is provided. To start the tool,

depress the lock-off lever and pull the switch trigger.

The tool speed increases by increasing pressure on the

switch trigger. Release the switch trigger to stop.

►

Fig.7:

1.

 Switch trigger

2.

 Lock-off lever
