- 5 -

defi nitely  fi x the hood using the screws

A

 (Fig.4). For the

various installations use screws and screw anchors suited to
the type of wall (e.g. reinforced concrete, plasterboard, etc.). If
the screws and screw anchors are provided with the product,
check that they are suitable for the type of wall on which the
hood is to be fi xed.

• Fixing the decorative telescopic fl ue

Arrange the electrical power supply within the dimensions
of the decorative fl ue. If your appliance is to be installed in
the ducting version or in the version with external motor,
prepare the air exhaust opening. Adjust the width of the
support bracket of the upper fl ue (Fig.3). Then fi x it to the
ceiling using the screws

A

 (Fig.3) in such a way that it is in line

with your hood and respecting the distance from the ceiling
indicated in Fig.2. Connect the fl ange

C

 to the air exhaust hole

using a connection pipe (Fig.4). Insert the upper fl ue into the
lower fl ue. Fix the lower fl ue to the hood using the screws

B

provided (Fig.4), extract the upper fl ue up to the bracket and
fi x it with the screws

B

 (Fig.3).

To transform the hood from a ducting version into a fi ltering
version, ask your dealer for the charcoal fi lters and follow the
installation instructions.

• Filtering version

Install the hood and the two fl ues as described in the para-
graph for installation of the hood in ducting version. To as-
semble the fi ltering fl ue refer to the instructions contained
in the kit. If the kit is not provided, order it from your dealer
as accessory. The fi lters must be applied to the suction unit
positioned inside the hood. They must be centred by turning
them 90 degrees until the stop catch is tripped  (Fig.6).

USE AND MAINTENANCE

•

We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance
is left running for 15 minutes after the food is cooked, in
order to thoroughly eliminate all contaminated air.
The eff ective performance of the cooker hood depends on
constant maintenance; the anti-grease fi lter and the active
carbon fi lter both require special attention.

• The anti-grease fi lter

 is used to trap any grease particles

suspended in the air, therefore is subject to saturation (the
time it takes for the fi lter to become saturated depends on
the way in which the appliance is used).
- To prevent potential fi re hazards, the anti-grease fi lters
should be washed a minimum of every 2 months (it is
possible to use the dishwasher for this task).
- After a few washes, the colour of the fi lters may change.
This does not mean they have to be replaced.
If the replacement and washing instructions are not followed,
the anti-grease fi lters may present a fi re hazard.

• The active carbon fi lters

 are used to purify the air which

is released back into the room. The fi lters are not washable
or re-usable and must be replaced at least once every four
months. The active carbon fi lter saturation level depends on
the frequency with which the appliance is used, the type of
cooking performed and the regularity with which the anti-
grease fi lters are cleaned.
• Clean the cooker hood frequently, both inside and outside,
using a cloth which has been dampened with denatured
alcohol or neutral,

non

-abrasive liquid detergents.

• The light on the cooker hood is designed for use during
cooking and not for general room illumination. Extended
use of the light reduces the average duration of the bulb.

• Replacing halogen light bulbs

(fi g.7).

To replace the halogen light bulbs

B

, remove the glass pane

C

 using a lever action on the relevant cracks.

Replace the bulbs with new ones of the same type.

Caution:

 do not touch the light bulb with bare hands.

•Commands:

(fig.8) mechanical the key symbols are ex-

plained below:

A

 = LIGHT

B

 = OFF

C

 = SPEED I

D

= SPEED II

E

 = SPEED III

• Commands:

(fi g.9)

luminous

the key symbols are explained

below:

A

 = LIGHT

B

 = OFF

C

 = SPEED I

D

= SPEED II

E

 = SPEED III

F

= AUTOMATIC STOP TIMER - 15 minutes

(*)

•

If your appliance does not have the

INTENSIVE

 speed

function, press key E for two seconds and it will be activated
for 10 minutes after which it will return to the previously set
speed. When the function is active the LED fl ashes. To interrupt
it before the 10 minutes have expired press key

E

again.

•

 By pressing key

F

for two seconds (with the hood switched

off ) the “

clean air

” function is activated. This function switches

the appliance on for ten minutes every hour at the fi rst speed.
As soon as this function is activated the motor starts up at the
fi rst speed for ten minutes, During this time key

F

and key

C

must fl ash at the same time. After ten minutes the motor

switches off  and the LED of key

F

remains switched on with

a fi xed light until the motor starts up again at the fi rst speed
after fi fty minutes and keys

F

and

C

start to fl ash again for ten

minutes and so on. By pressing any key for the exclusion of
the hood light the hood will return immediately to its normal
functioning (e.g. if key D is pressed the “

clean air

” function is

deactivated and the motor moves to the 2nd speed straight
away. By pressing key

B

the function is deactivated).

(*)

 The

“automatic stop timer”

delays stopping of the hood,

which will continue functioning for 15 minutes at the operat-
ing speed set at the time this function is activated.

• Active carbon/grease fi lter saturation:

- When button

A

  fl ashes at a frequency of

2 seconds

, the

grease

 fi lters must be cleaned.

- When button

A

  fl ashes at a frequency of

0.5 seconds

, the

carbon

 fi lters must be replaced.

After the clean fi lter has been replaced, the electronic memory
must be reset by pressing button

A

 for approximately

5

seconds

, until the light on the button stops fl ashing.

• Commands:

(fi g.10).

Push-button A

= on/off  lights switch

Push-button B

= on/off  cooker hood switch.  The appliance

switches on at speed level 1,  If the cooker hood is on depress
the push-button for 2 sec. to switch off  the cooker hood.  If
the cooker hood is at speed level 1 it will not be necessary
to depress the push-button to switch the cooker hood off .
Decreases the motor speed.

Display C

= indicates the motor speed level selected and

activates the timer.
