- 4 -

ENGLISH

GB

GENERAL

Carefully read the following important information regarding
installation safety and maintenance. Keep this information
booklet accessible for further consultations.
The appliance has been designed for use in the ducting
version (air exhaust to the outside – Fig.1B), fi ltering version
(air circulation on the inside – Fig.1A) or with external motor
(Fig.1C).

SAFETY PRECAUTION

1.

Take care when the cooker hood is operating simultane-

ously with an open fi replace or burner that depend on the air
in the environment and are supplied by other than electrical
energy, as the cooker hood removes the air from the environ-
ment which a burner or fi replace need for combustion. The
negative pressure in the environment must not exceed 4Pa
(4x10-5 bar). Provide adequate ventilation in the environment
for a safe operation of the cooker hood.
Follow the local laws applicable for external air evacuation.

Before connecting the model to the electricity network:

- control the data plate (positioned inside the appliance)
to ascertain that the voltage and power correspond to the
network and the socket is suitable. If in doubt ask a qualifi ed
electrician.
- If the power supply cable is damaged, it must be replaced
with another cable or a special assembly, which may be
obtained direct from the manufacturer or from the Technical
Assistance Centre.
- This device must be connected to the supply network
through eiter a plug

fused 3A

or hardwired to a

2 fase

spur

protected by

3A fuse.

2. Warning !
In certain circumstances electrical appliances may be a
danger hazard.
A) Do not check the status of the filters while the cooker
hood is operating
B) Do not touch bulbs or adjacent areas, during or straight
after prolonged use of the lighting installation.
C) Flambè cooking is prohibited underneath the cooker
hood
D) Avoid free flame, as it is damaging for the filters and
a fire hazard
E )   C o n s t a n t l y   c h e c k   f o o d   f r y i n g   t o   a v o i d   t h a t   t h e
overheated oil may become a fire hazard
F )   D i s c o n n e c t   t h e   e l e c t r i c a l   p l u g   p r i o r   t o   a n y
maintenance.
G) This appliance is not intended for use by young children
or infirm persons without supervision
H) Young children should be supervised to ensure they
do not play with the appliance
I) There shall be adequate ventilation of the room when
the rangehood is used at the same time as appliances
burning gas or other fuels
L) There is a risk of fire if cleaning is not carried out in
accordance with the instructions

This appliance conforms to the European Directive EC/2002/96,
Waste Electrical and Electronic Equipment (WEEE). By making

sure that this appliance is disposed of in a suitable manner,
the user is helping to prevent potential damage to the
environment or to public health.

The

 symbol on the product or on the accompanying

paperwork indicates that the appliance should not be treated
as domestic waste, but should be delivered to a suitable
electric and electronic appliance recycling collection point.
Follow local guidelines when disposing of waste. For more
information on the treatment, re-use and recycling of this
product, please contact your local authority, domestic waste
collection service or the shop where the appliance was
purchased.

INSTALLATION INSTRUCTIONS

Assembly and electrical connections must be carried out
by specialised personnel.

• Electric Connection

The appliance has been manufactured as a class II, therefore
no earth cable is necessary.
The connection to the mains is carried out as follows:
BROWN =

L

 line

BLUE =

N

 neutral

If not provided, connect a plug for the electrical load indi-
cated on the description label. Where a plug is provided, the
cooker hood must be installed in order that the plug is easily
accessible.  An omnipolar switch with a minimum opening of
3mm between contacts, in line with the electrical load and
local standards, must be placed between the appliance and
the network in the case of direct connection to the electrical
network.

Warning

:

When connecting the appliance to the electricity supply, make
sure that the mains socket has an earth connection.
After fi tting the ducted cooker hood, make sure that the
electrical plug is in a position where it can be accessed easily.
If the appliance is connected directly to the electricity supply,
an omnipolar switch with a minimum contact opening of
3 mm must be placed in between the two; its size must
be suitable for the load required and it must comply with
current legislation.

•

 The minimum distance between the support surfaces of

the cooking pots on the cooker top and the lowest part of
the cooker hood must be at least 65 cm. If a connection tube
composed of two parts is used, the upper part must be placed
outside the lower part. Do not connect the cooker hood ex-
haust to the same conductor used to circulate hot air or for
evacuating fumes from other appliances generated by other
than an electrical source. Before proceeding with the assembly
operations, remove the anti-grease fi lter(s) (Fig.5) so that the
unit is easier to handle.
In the case of assembly of the appliance in the suction version
prepare the hole for evacuation of the air.

•

 We recommend the use of an air exhaust pipe with a

diameter of 150. If a pipe with a smaller diameter is used, the
effi

  ciency of the product may be reduced and its operation

may become noisier.

• Fixing to the wall

Drill the holes

A

 respecting the distances indicated (Fig.2). Fix

the appliance to the wall and align it in horizontal position
to the wall units. When the appliance has been adjusted,
