15

Dear customer, we thank you for purchasing our product.

PLEASE  READ  THE  INSTRUCTIONS  THOROUGHLY  PRIOR  TO  THE  INSTALLATION  AND

FIRST OPERATION OF THE WATER HEATER.

THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH

REDUCED  PHYSICAL,  SENSORY  OR  MENTAL  CAPABILITIES,  OR  LACK  OF  EXPERIENCE

AND  KNOWLEDGE,  UNLESS  THEY  HAVE  BEEN  GIVEN  SUPERVISION  OR  INSTRUCTION

CONCERNING USE OF THE APPLIANCE BY PERSON RESPONSIBLE FOR THEIR SAFETY.

CHILDREN  SHOULD  BE  SUPERVISED  TO  ENSURE  THAT  THEY  DO  NOT  PLAY  WITH  THE

APPLIANCE.

This  water  heater  has  been  manufactured  in  compliance  with  the  relevant  standards  and  tested  by  the  relevant

authorities as indicated by the Safety Certificate and the Electromagnetic Compatibility Certificate. Its basic technical

properties  are  stated  upon  the  nameplate,  glued  between  the  connection  pipes.  The  water  heater  may  be  connected

to water and electric power supply only by a qualified specialist. The reach in its inside due to the repair or removal of

limestone and checking and replacement of anti-corrosion protection anode may be performed only by an authorised

service workshop.

INSTALLATION

The water heater shall be built as close as possible to the outlets.It has to be fitted to the wall using appropriate rag bolts

with minimum diameter of 8 mm. In case the wall in question cannot support the weight three times that of the water

heater filled with water, the relevant section of the wall where the heater is to be installed, must be suitably reinforced.

GBK water heater must be mounted to the wall in the upright position. Only GBL 50 and GRL 80 models may be mounted

horizontally to the ceiling. These water heaters may not be wall- or floor-mounted as this could damage the heaters.

TECHNICAL CHARACTERISTICS OF WATER HEATER

Type

GBL 50

GBL 80

GBK 80 L/D

GBK 100 L/D

GBK 120 L/D

GBK 150 L/D

GBK 200 L/D

Model

GBL 50 N

GBL 80 N

GBK 80 LN/RN GBK 100 LN/RN GBK 120 LN/RN GBK 150 LN/RN GBK 200 LN/RN

Volume                                [l]

50

80

80

100

120

150

200

Rated pressure                  [MPa]

0,6

Weight / Filled with water  [kg]

27/77

33/113

51/131

56/156

62/182

72/222

90/290

Anti-corrosion protection of tank

Emailed & Mg Anode

Power of electrical heater    [W]

2000

Connection voltage             [V

~

]

230

Protection class

I

Degree of protection

IP 25

Heating time to 75°C

1)

          [h]

1

55

3

05

3

05

3

55

4

35

5

45

7

40

Quantity of mixed water at 40° [l]

80

117

151

189

226

276

360

Energy consumption

2)

         [kWh/24h]

1,20

1,46

1,39

1,58

1,77

2,05

2,50

1) Time required for the electric heating element to heat the entire tank volume, at the water supply temperature of 15°C.

2) Power consumption required for the temperature of water in the water heater to be maintained at 65°C, at the room temperature

    of 20°C, measured in accordance with the DIN 44532 standard.

TECHNISCHE EIGENSCHAFTEN DES WARMWASSERBEREICHERS

GBK 80 L/D

GBK100 L/D

GBK 120 L/D

GBK 150 L/D

GBK 200 L/D

Nominal pressure                                  [MPa]

                         0,6

Max. inlet temperature of heating medium    [°C]

                        85

Surface of transmitter                             [m

2

]

0,72

0,88

Heat flow of heat transmitter

3)

                [W]

14400

17600

3) Heating medium: inlet temperature 70°C, flow 3000 l/h.

    Sanitary water: inlet temperature 10°C, outlet temperature 45°C, flow 437 l/h.
