Induction hobs may whistle or creak during normal operation.

These noises actually come from the cookware and are linked to the pan

bottoms' characteristics (for example, when the bottoms are made from

different layers of material or are irregular).

These noises may vary according to the type of cookware used, and to the

amount of food, it contains and are not the symptom of something wrong.

SOUNDS PRODUCED DURING OPERATION

TROUBLESHOOTING

•  Check that the electricity supply has not been shut off.

•  If you are unable to turn the hob off after using it, disconnect it from the

power supply.

•  If alphanumeric codes appear on the display when the hob is switched on,

consult the following table for instructions.

Please note: The presence of water, liquid spilled from pots or any objects

resting on any of the hob buttons can accidentally activate or deactivate

the control panel lock function.

SUPPORT

DISPLAY CODE

DESCRIPTION

POSSIBLE CAUSES

SOLUTION

F0E1

Cookware is detected, but it is not

compatible with the requested

operation.

The cookware is not well positioned on

the cooking zone or is not compatible

with one or more cooking zones.

Press the On/Off button twice to remove

the F0E1 code and restore the cooking

zone's functionality. Then, try to use the

cookware with a different cooking zone or

use different cookware.

F0E7

Wrong power cord connection.

The power supply connection is not

exactly as indicated in the “ELECTRICAL

CONNECTION“ paragraph.

Adjust the power supply connection

according to the “ELECTRICAL CONNECTION“

paragraph.

F0EA

The control panel switches off because

of excessively high temperatures.

The internal temperature of electronic

parts is too high.

Wait for the hob to cool down before using

it again.

F0E2, F0E4, F0E6,

F0E8, F0EC, F1E1,

F6E1, F7E5, F7E6

Disconnect the hob from the power supply.

Wait a few seconds, then reconnect the hob to the power supply.

If the problem persists, call the service centre and specify the error code that appears on the display.

d E

[when the hob is off]

The hob does not switch heat up.

The functions do not come on.

DEMO MODE on.

Follow the instructions in the “DEMO

MODE“ paragraph.

e.g.

:

The hob does not allow a special

function to be activated.

The power regulator limits the power

levels in accordance with the maximum

value set for the hob.

See paragraph “Power management“.

e.g.

[Power level lower than

level requested]

The hob automatically sets a minimum

power level to ensure that the cooking

zone can be used.

The power regulator limits the power

levels in accordance with the maximum

value set for the hob.

See paragraph “Power management“.

In the event of any operation problems, contact a Franke Technical Service

Centre.

Never use the services of unauthorized technicians.

When contacting the customer service, please provide the following

information:

– type of fault

– appliance model (Art.)

– serial number (S.N.)

This information is given on the data plate. The data plate is attached on

the bottom side.

You must also have proof of purchase if you‘re still within the warranty

period.

XXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXXXXXXX

Made in X

Type: XXX

Mod.: XXX

01

XXXX XXX XXXXX

XX XXXX XXXXX

XXXXXXXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
