18

OPERATION AND

USE OF THE COOKTOP

ONLY USE COOKWARE SUITABLE FOR INDUCTION HOBS.

When a cooking are is turned on, the bottom of the saucepan heats.

The cooking area only heats thanks to the heat given by the saucepan.

The cooktop automatically detects the size of the saucepan.

The heating power is to be chosen based on what shall be cooked.

Please find below a short table:

SETTING AREAS

1 - 2

Melt

Heat

Sauces, butter, chocolate,

gelatine

Precooked dishes

2 - 3

Whisk

Defrost

Rice, pudding and cooked

dishes

Vegetables, fish, frozen food

3 - 4

Steam

Vegetables, fish, meat

4 - 5

Boil

Boiled potatoes, soups, pasta

Fresh vegetables

6 - 7

Cook over a low heat

Meat, liver, eggs, sausages

Goulash, rolate, tripe

7 - 8

Cook

Fry

Potatoes, donuts, cakes

9

Fry, bring to the boil

Steaks, omelettes

Boil

P

Fry, bring to the boil

Bring to the boil big

quantities of water

Remark: heating time of cooktops is shorter than the gas cookers.

BASIC FUNCTIONS

See table of the corresponding model in the previous page.

BRIDGE FUNCTION

This function allows having cooking areas 1-2 and/or 3-4 working at the same time.

To enable:

- Enable the cooktop;

For "90":

press simultaneously the symbols

+

::

- the symbol

(solo

display

destro)

 will be displayed on the screen of the front cooking area;

- Push the keys + and – to set power.

Note: this function can only be activated between the 2 right or the 2 left plates (not the

two centre plates).

For "90 Plus":

press simultaneously the symbols:

- The

 symbols will appear on the display of the two BRIDGE cooking areas;

- Set the power with the slider of the front cooking area.

DEACTIVATION of the BRIDGE function:

For "90":

press simultaneously the symbols

+

:.

For "90 Plus":

press simultaneously the symbols:

BOOSTER FUNCTION

The Booster strengthens power, so that big quantities can be heated (e.g. water to cook

pasta).

This power increase is enabled for max. 10 minutes.

For "90":

- Turn on the cooker;

- select the cooking area;

- touch (+) until on the screen   is displayed on the back cooking area.

Note: it is not possible to only set to   one right or one left plate at the time (and

no more than 2 in total).
If the outermost plate is set to  , the one near cannot be set to exceed the   level.
If the innermost plate is set to  , the outer one switches off.

For "90 Plus":

- Turn on the cooker;
- touch the slider to bring power to   and  then the key (+).
At the end of the Booster mode, power is automatically reduced to  .

If a zone is set to   , the zone near cannot exceed level  .

KEEP WARM FUNCTION

Version "90"

42°C - Keeping temperature of cooked dishes:

Turn on the cooker;

Select the cooking area;

Touch (+) and then (-):  the

symbol will appear.

Version "90 Plus"

Turn on the cooker;
Touch the key

 regarding the concerned cooking area and select one of the 3 levels

of temperature:
42°C - Keeping temperature of cooked dishes

;

70°C - Keep on cooking

;

94°C - Bring to the boil

;

Shutdown of the cooker

To shutdown the cooking area:

Touch the key ( - ) until 0 is displayed on the screen of the cooking area.

If the cooking area is still too hot, the residual heat is specified  .

Turn off the cooker
Touch the key

 : all cooking areas are deactivated.

On the display of the cooking areas that are still too hot, the symbol is displayed  .

Do not touch the cooking areas until the lamp

  is on.

TIMER FUNCTION

AND AUTOMATIC SHUTDOWN

The timer has two functions:

1 – TIMER;

2 – AUTOMATIC SHUTDOWN of one or more cooking areas.

It is possible to set a duration up to 99 minutes for the “90” version and 119 minutes for

the “90 Plus” version.

Once the time set is over, on the display regarding time 00 is shown and a sound warn-

ing is activated that can be deactivated pushing keys (+) or (-).

TIMER

To set:
1. If off, turn the hob on using the

  key and touch (+) and (-) at the same time.

(on the Plus version the lamp is on

 );

2. Set the desired time touching keys (+) and (-).

Timer starts passing.

To modify time repeat the procedure from point 1.

To cancel timer:

1. If off, turn the hob on and touch (+) and (-) at the same time.
(on the Plus version the lamp is on

).

2. Touch the key ( - ) to bring time to 00.
