Kaiser KCT 777 - Инструкция по эксплуатации - Страница 44

44

EN

COOKING ZONES CONTROL
MODEL KCT 6933…



Switching on the hob



 Press

the

key

1

 and hold it within 2 sec. to

activate the control: the adjustment level
indicator

2

 is set to «0» while the decimal

point

3

 flashes.

Perform the next operation within 10 seconds;
otherwise the device will switch off automatically.



Adjusting of power and of timer using the keys
(+)

4

и

 (

–

)

5

.


Use the (

+

) and (

–

) keys to adjust the functions,

the setting of the plates and the required time on
timer/ minute counter.




 The

(

+

) and (

–

) controls are common to

functions described above. Accordingly, to
regulate the power of the hob, first select
the zone with key

6

, then adjust the

relative power level using the (

+

) and (

–

)

keys; this done.



  Select the timer function with key

7

 and

proceed to set the duration, likewise using
the (

+

) or (

–

) keys.

Switching on the cooking area

Once the device has been activated, using the key

1

, switch on the cooking area (within 10 seconds)

as follows:




  Press one of the keys

4

 to select the

cooking area required. The relative display

2

 will indicate a «0» and the decimal point

3

 will illuminate to show that the cooking

area has been activated.



  Use the (

+

)

4

 and (

–

)

5

 keys to adjust the

heat level (from 1 to 9).



These keys have a function of repeating, so if you
press and hold down one of these keys the warm
level will be increased or decreased accordingly.

1

3

5

2

4

6

7
