Additional information
11
80
En
Specifications
Audio section
Rated power output
Front, Center, Surround
. . . . . . . . 130 W per channel (1 kHz, 6
Ω
, 1 %)
. . . . . . . . . . . . . . . . . . . . . . 100 W per channel
(20 Hz to 20 kHz, 8
Ω
, 0.09 %)
Total Harmonic Distortion
. . . . . . 0.06 % (20 Hz to 20 kHz, 8
Ω
, 95 W/ch)
Frequency response (LINE Pure Direct mode)
. . . . . . . . . . . . . . . . . . . . 5 Hz to 100 kHz dB
Guaranteed speaker impedance
FRONT : A, B . . . . . . . . . . . . . . . . . . 6
Ω
to
16
Ω
FRONT : A+B . . . . . . . . . . . . . . . . 12
Ω
to
16
Ω
SURROUND, CENTER . . . . . . . . . . 6
Ω
to
16
Ω
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . 200 mV/47 k
Ω
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . 200 mV/2.2 k
Ω
Signal-to-Noise Ratio
(IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 dB
Video section
Signal level
Composite . . . . . . . . . . . . . . . . . . . 1 Vp-p (75
Ω
)
Component Video . . . . . . . . . Y: 1.0 Vp-p (75
Ω
)
PB, PR: 0.7 Vp-p (75
Ω
)
Corresponding maximum resolution
Component Video . . .1080i (1125i)/720p (750p)
Tuner section
Frequency Range (FM) . . . 87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . 75
Ω
unbalanced
Frequency Range (AM). . . . 531 kHz to 1602 kHz
Antenna (AM) . . . . . . . . . . . . . . . . . Loop antenna
Digital In/Out section
HDMI terminal . . . . . . . . . . . . . . . Type A (19-pin)
HDMI output type . . . . . . . . . . . . . . . . 5 V, 100 mA
USB terminal. . . . . . USB2.0 Full Speed (Type A)
iPod terminal . . . . . USB, and Video (Composite)
Miscellaneous
Power Requirements
. . . . . . . . . . . . . AC 220 V to 230 V, 50 Hz/60 Hz
Power Consumption . . . . . . . . . . . . . . . . . .245 W
In standby . . . . . . . . . . . . . . . . . . . . . . . . 0.45 W
Dimensions
. . . . . 420 mm (W) x 158 mm (H) x 347.7 mm (D)
Weight (without package) . . . . . . . . . . . . . . 9.1 kg
Furnished Parts
Microphone (for Auto MCACC setup) . . . . . . . . 1
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Dry cell batteries (AAA size IEC R03)
. . . . . . . 2
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1
iPod cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
These operating instructions
Note
• The specifications are applicable when the
power supply is 230 V.
• Specifications and the design are subject
to possible modifications without notice,
due to improvements.
Cleaning the unit
• Use a polishing cloth or dry cloth to wipe
off dust and dirt.
• When the surface is dirty, wipe with a soft
cloth dipped in some neutral cleanser
diluted five or six times with water, and
wrung out well, and then wipe again with a
dry cloth. Do not use furniture wax or
cleansers.
• Never use thinners, benzine, insecticide
sprays or other chemicals on or near this
unit, since these will corrode the surface.
Published by Pioneer Corporation.
Copyright © 2010 Pioneer Corporation.
All rights reserved.
