16 ENGLISH

Installing powder filter (HEPA) and

prefilter (for dry dust)

CAUTION:

Never pick up water or other liq-

uids or wet dusts when using the powder filter.

Picking up such things may cause the powder filter

breakage.

To use powder filter:

1.

  Place the prefilter into the tank aligning the mount-

ing position markings on the prefilter and tank.

2.

  Set the damper into the prefilter, and then place

the powder filter over the damper aligning the mounting

position markings on the powder filter and prefilter.

3.

  Mount the head unit over the tank and secure

them with the locking latches.

►

Fig.11:

1.

 Head unit

2.

 Powder filter (HEPA)

3.

 Damper

4.

 Prefilter

5.

 Tank

6.

 Mounting

position marking

NOTICE:

Before using the powder filter, make

sure that prefilter and damper are used together.

 It

is not allowed to install powder filter alone.

Installing paper pack

Optional accessory

WARNING:

Before using a paper pack, make

sure that the prefilter is used together.

 Failure to

use the prefilter together may cause unusual noise

and heat, resulting in a fire.

NOTICE:

Never pick up water or other liquids

or wet dusts when using a paper pack.

 Picking up

such things may cause the paper pack breakage.

NOTICE:

Before using a paper pack, make sure

that the powder filter, damper and prefilter are

always used together.

1.

  Unfold a paper pack.

2.

  Align the paper pack opening with the dust intake

of the tank.

3.

  Install the paper pack into the tank with its card

-

board opening hooked on the paper pack holder.

►

Fig.12:

1.

 Paper pack

2.

 Cardboard opening

3.

 Paper pack holder

4.

 Dust intake

Installing polyethylene bag

With a polyethylene bag installed in the tank, you can

easily empty the tank without letting your hands dirty.

Lay a polyethylene bag over the tank, and slip one side

of the top edge of the bag at its open end in between

the holder plate and the front wall of the tank.

►

Fig.13:

1.

 Holder plate

2.

 Front wall of tank

3.

 Polyethylene bag

Spread the other top edges of the bag outwards over

the top rims of the tank. Place the prefilter over the poly-

ethylene bag to fasten the opening of the bag securely.

►

Fig.14:

1.

 Prefilter

NOTE:

 A polyethylene bag available on the

market can be used. 0.04 mm or thicker one is

recommended.

NOTE:

 Too much dust will tear the bag easily, so

do not collect the dust more than the half of the bag

capacity.

Emptying tank with polyethylene bag

WARNING:

Always make sure that the cleaner

is switched off and the battery cartridges are

removed before emptying the tank.

 Failure to do

so may cause an electric shock and serious personal

injury.

NOTICE:

Do not apply a great impact on the

tank.

 Applying a great impact may cause deformation

and damage to the parts.

NOTICE:

Empty the tank at least once a day

although this depends on picked-up dust volume

in the tank.

 Or, the suction force will weaken and the

motor may be broken.

NOTICE:

Do not grab the hooks or latches when

emptying the tank.

 Grabbing the hooks or latches

may cause them to break.

Release the locking latches and lift the head unit up off the tank.

Shake off dust from the prefilter before lifting the filter

away from the tank.

Then remove the polyethylene bag out of the tank,

closing the opening of the bag by hand.

►

Fig.15:

1.

 Polyethylene bag

2.

 Tank

NOTE:

 Take the polyethylene bag out of the tank

carefully to avoid it from being scratched and torn by

the edges inside the tank.

NOTE:

 Empty the polyethylene bag before it

becomes full. Too much dust in the tank may cause

the polyethylene bag to be torn.

Installing multi hook

Use the multi hook to hold a hose, accessories and

attachments not in use in place, and you can quickly

take them out according to your preferences.

►

Fig.16

Place the multi hook over the mounting base at the rear

of the cleaner, setting the rails on the multi hook along

the grooves on the mounting base.

►

Fig.17:

1.

 Multi hook

2.

 Mounting base

Installing MAKPAC adapter

Optional accessory

Connectable and stackable MAKPAC storage cases

can be installed on top of the cleaner with an optional

adapter. The cases are available in many sizes and

styles to suit your preferences.
Place the mounting base hook over the handle of the

cleaner with its mounting surface facing upwards when

the handle is folded into the closed position.

►

Fig.18:

1.

 Mounting base hook

2.

 Mounting surface

3.

 Handle
