CAUTION:

This equipment is designed to permit the connection of the earthed conductor of the DC supply circuit to
the earthing conductor at the equipment.

If this connection is made, all of the following must be met:

• This equipment must be connected directly to the DC supply system earthing electrode conductor or

to a bonding jumper from an earthing terminal bar or bus to which the DC supply system earthing
electrode conductor is connected.

• This equipment must be located in the same immediate area (such as adjacent cabinets) as any

other equipment that has a connection between the earthed conductor of the same DC supply circuit
and the earthing conductor, and also the point of earthing of the DC system. The DC system must be
earthed elsewhere.

• The DC supply source is to be located within the same premises as the equipment.
• Switching or disconnecting devices must not be in the earthed circuit conductor between the DC

source and the point of connection of the earthing electrode conductor.

HPE 1600W Flex Slot Platinum Hot Plug Power Supply

Specification

Value

Input requirements

Rated input voltage

200 to 240 VAC

240 VDC (China only)

Rated input frequency

50 Hz to 60 Hz

Rated input current

8.7 A at 200 VAC

7.2 A at 240 VAC

Maximum rated input power

1734 W at 200 VAC

1720 W at 240 VAC

BTUs per hour

5918 at 200 VAC

5884 at 240 VAC

Power supply output

Rated steady-state power

1600 W at 200 VAC to 240 VAC input

1600 W at 240 VDC input

Maximum peak power

2200 W for 1ms (turbo mode) at 200 VAC to 240 VAC
input

HPE 1600W Flex Slot Platinum Hot Plug Power Supply

153
